Part One Hardware Installation Guide

Chapter 1 Product Instruction

1.1 Introduction

1.2 Rear Panel

Picture 1.3.1 Rear Panel

Power Socket: Three-core power socket is adopted,please connect female head

of power cord to the socket, and connect the AC power supply with male head.

or causing body injuries.

1). Please remove the power socket before cleaning the switch. Don’ wipe the switch with wet cloth

or wash the switch with liquid.

2). Don’t stock the device in damp environment or near water, to avoid water or moisture penetrating into

the inner device.

3). Don’t put the device on a unstable box or desk, the device will get damaged from falling.

7). Please wear anti-static wrist strap when change the interface board,to avoid the static electricity

damage the board.

2.2 Check Installation Environment

The switch is for indoor use only, please pay attention to the following problems when install the switch

in a cabinet or put the device directly on the desktop.

1) The air vents of switch must have enough space to dissipate the heat inside enclosure.

2.3 Installation Tools

1) Flathead screw driver

2) Cross screw driver
