Qtech QSW-8200-28T-POEAC- DC [23/74] Ip route

User Manual

Chapter 2. Commands for Static Route 23

www.qtech.ru

Chapter 2 COMMANDS FOR STATIC ROUTE

2.1 ip route

 Command: ip route {<ip-prefix> <mask> | <ip-prefix>/<prefix-length>} {<gateway-

address> | <gateway-interface>} [<distance>]

 no ip route {<ip-prefix> <mask> | <ip-prefix>/<prefix-length>}

[<gateway-address> | <gateway-interface>] [<distance>]

 Function: Configure the static route. The “no ip route {<ip-prefix> <mask> | <ip-

prefix>/<prefix-length>} [<gateway-address> | <gateway-interface>] [<distance>]”

command deletes the static route.

 Parameter: The <ip-prefix> and <mask> are respectively destination IP address and

subnet mask, shown in dotted decimal notation; <ip-prefix> and <prefix-length> are

respectively the destination IP address and the length of prefix; <gateway-address> is

the next-hop IP address shown in dotted decimal notation; <gateway-interface> is the

next-hop interface, < distance > is the manage distance of route management, ranging

between 1～255.

 Default: The management distance of static routing is defaulted at 1.

 Command Mode: Global Mode.

 Usage Guide: When configuring the next-hop of static routing, both by specifying the

next-hop IP address of the route data packet and the exit interface are available.

 The default distance values of each route type in the layer 3 switch of our company are

listed below:

Route Type

Distance Value

Direct Route

Static Route

OSPF

110

RIP

120

IBGP

200

EBGP

 The direct route has the highest priority when each route management distance value

remain unchanged and followed by static route, EBGP, OSPF, RIP, IBGP.

 Example:

 Example 1. Add a static route
