QTECH QSW-2100-12T Configuration Guide (CLI)
5 IP services
156
The Option field of a DHCP packet records location of a DHCP client. The administrator can
locate a DHCP client through the Option field and control client security and accounting. The
device configured with DHCP Snooping and Option can perform related process according to
Option field status in the packet.
Prerequisite
N/A
5.7.3 Default configurations of DHCP Snooping
Default configurations of DHCP Snooping are as below.
Function
Default value
Global DHCP Snooping status
Disable
Interface DHCP Snooping status
Enable
Interface trust/untrust status
Untrust
DHCP Snooping in support of Option 82
Disable
5.7.4 Configuring DHCP Snooping
Generally, ensure that the QSW-2100-12T interface connected to DHCP server is in trust state,
while the interface connected to user is in distrust state.
If enabling DHCP Snooping without configuring DHCP Snooping supporting Option function,
the QSW-2100-12T will do nothing to Option fields in the packets. For packets without
Option fields, the QSW-2100-12T still does not do insertion operation.
By default, DHCP Snooping of all interfaces is enabled, but only when global DHCP
Snooping is enabled, interface DHCP Snooping can take effect.
Configure DHCP Snooping for the QSW-2100-12T as below.
Step
Command
Description
1
QTECH#config
Enter global configuration mode.
2
QTECH(config)#ip dhcp
snooping
Enable global DHCP Snooping.
3
QTECH(config)#ip dhcp
snooping port-list
port-
list
(Optional) enable interface DHCP
Snooping.
4
QTECH(config)#interface
port
port-id
Enter physical layer interface configuration
mode.
5
QTECH(config-port)#ip dhcp
snooping trust
Configure the trusted IPv4 interface of
DHCP Snooping.
6
QTECH(config-port)#ip dhcp
snooping information option
vlan-list
vlan-list
(Optional) configure the lists of VLANs
that support Option 82 through DHCP
Snooping.
