QTECH QSW-2100-12T Configuration Guide (CLI)
7 QoS
185
No.
Command
Description
2
QTECH#show mls qos queue
Show queue weight information on the
interface.
3
QTECH#show mls qos queue
shaping port-list
port-list
Show queue bandwidth guarantee
information on the interface.
7.5 Configuring traffic classification and traffic policy
7.5.1 Preparing for configurations
Scenario
Traffic classification is the basis of QoS. You can classify packets from an upstream device by
priorities or ACL rule.
A traffic classification rule will not take effect until it is bound to a traffic policy. Apply traffic
policy according to current network loading conditions and period. Usually, the QSW-2100-
12T limits the rate of transmitting packets according to configured rate when packets enter the
network, and remarks priority according to service feature of packets.
Prerequisite
Enable global QoS.
7.5.2 Default configurations of traffic classification and traffic policy
Default configurations of traffic classification and traffic policy are as below.
Function
Default value
Traffic policy statistics status
Disable
7.5.3 Creating traffic classification
Create traffic classification for the QSW-2100-12T as below.
Step
Command
Description
1
QTECH#config
Enter global configuration mode.
2
QTECH(config)#class-map
class-map-name
[ match-all |
match-any ]
Create traffic classification and enter
traffic classification cmap configuration
mode.
3
QTECH(config-
cmap)#description
string
(Optional) describe traffic classification.
