QTECH QSW-2100-12T Configuration Guide (CLI)
10 Reliability
279
Step
Command
Description
6
QTECH(config)#switchport
backup restore-mode
{ disable | neighbor-
discover | port-up }
(Optional) configure restoration mode.
In an interface backup group, an interface is either a primary interface or a backup
interface.
In a VLAN, an interface or a LAG cannot be a member of two interface backup
groups simultaneously.
10.2.5 (Optional) configuring FS on interfaces
After FS is successfully configured, the primary/backup link will be switched; namely,
the current link is switched to the backup link (without considering Up/Down status
of the primary/backup interface).
In the FS command, the backup interface number is optional. If the primary
interface is configured with multiple interface backup groups in different VLANs, you
should input the backup interface number.
Configure FS on interfaces for the QSW-2100-12T as below.
Step
Command
Description
1
QTECH#config
Enter global configuration mode.
2
QTECH(config)#interface
interface-type primary-
interface-number
Enter physical layer interface configuration
mode or LAG configuration mode.
3
QTECH(config-
port)#switchport backup
[
interface-type
backup-
interface-number
] force-
switch
Configure FS on the interface.
Use the no switchport backup [ interface-
type backup-interface-number ] force-switch
command to cancel FS. Then, selecting the
current link according to link status are as
below:
If the Up/Down statuses of the two
interfaces are the same, the primary
interface is of high priority.
If the Up/Down statuses of the two
interfaces are different, the Up interface is
of high priority.
QTECH(config-
aggregator)#switchport
backup [
interface-type
backup-interface-number
]
force-switch
10.2.6 Checking configurations
Use the following commands to check configuration results.
