QTECH QSW-2100-12T Configuration Guide (CLI)
9 Security
259
Configure Circuit ID for the QSW-2100-12T as below.
Step
Command
Description
1
QTECH#config
Enter global configuration mode.
2
QTECH(config)#pppoeagent
circuit-id mode { onu |
switch }
Configure the padding mode of the Circuit
ID.
3
QTECH(config)#interface
port
port-id
Enter physical layer interface configuration
mode.
4
QTECH(config-
port)#pppoeagent circuit-
id
string
(Optional) set the Circuit ID to the
customized string.
In default mode, the Circuit ID contains an attached string. By default, the attached string is
set to the hostname of the switch. You can set it to a customized string.
Configure the attached string of the Circuit ID for the QSW-2100-12T as below.
Step
Command
Description
1
QTECH#config
Enter global configuration mode.
2
QTECH(config)#p
ppoeagent
circuit-id
attach-string
string
(Optional) configure the attached string of the Circuit ID.
If the Circuit ID is in default mode, attached string
configured by this command will be added to the Circuit
ID.
Configuring Remote ID
The Remote ID is padded with a MAC address of the switch or a client. In addition, you can
specify the form (binary/ASCII) of the MAC address.
Configure the Remote ID for the QSW-2100-12T as below.
Step
Command
Description
1
QTECH#config
Enter global configuration mode.
2
QTECH(config)#interface
port
port-id
Enter physical layer interface configuration
mode.
3
QTECH(config-
port)#pppoeagent remote-
id { client-mac | switch-
mac }
(Optional) configure PPPoE+ Remote ID to
be padded with the MAC address.
4
QTECH(config-
port)#pppoeagent remote-
id format { ascii |
binary }
(Optional) configure the padding modes of the
PPPoE+ Remote ID.
