QTECH QSW-2100-12T Configuration Guide (CLI)
11 System management
299
TLV type
Description
Optional/Required
5
System Name
Optional
6
System Description
Optional
7
System Capabilities
Optional
8
Management Address
Optional
Principle of LLDP
LLDP is a kind of point-to-point one-way issuance protocol, which sends link status of the
local device to peer end by sending LLDPDU (or sending LLDPDU when link status changes)
periodically from the local device to the peer end.
The procedure of packet exchange is as below:
When the local device transmits packet, it obtains system information required by TLV
from QNMS (Network Node Management), obtains configurations from LLDP MIB,
generates TLV, makes LLDPDU, encapsulates information to LLDP packets, and send
LLDP packets to the peer end.
The peer end receives LLDPDU and analyzes TLV information. If there is any change,
the information will be updated in neighbor MIB table of LLDP and the QNMS system
will be notified.
The aging time of Time To Live (TTL) in local device information in the neighbour node can
be adjusted by modifying the parameter values of aging coefficient, sends LLDP packets to
neighbour node, after receiving LLDP packets, neighbour node will adjust the aging time of
its neighbour nodes (sending side) information. Aging time formula, TTL = Min {65535,
(interval × hold-multiplier)}:
Interval: indicate the period for sending LLDP packets from the neighbor node.
Hold-multiplier: the aging coefficient of device information in neighbor node.
11.2.2 Preparing for configurations
Scenario
When you obtain connection information between devices through QNMS system for
topology discovery, the QSW-2100-12T needs to enable LLDP, notify their information to the
neighbours mutually, and store neighbour information to facilitate the QNMS system queries.
Prerequisite
N/A
11.2.3 Default configurations of LLDP
Default configurations of LLDP are as below.
