Kohler Confidant EFI EZT715 [12/100] Specifi cations
![Kohler Confidant EFI EZT715 [12/100] Specifi cations](/views2/1597366/page12/bgc.png)
12
Specifi cations
KohlerEngines.com 16 690 07 Rev. --
Engine Dimensions-with Low Profi le Air Cleaner-Engine Mounting Surface (PTO End)
A
B
B
C
E
F
G
H
I
J
L
P
N
M
O
D
T
S
R
Q
K
G
L L
Q
R
U
A 334.8 mm (13.18 in.) B 72.8 mm (2.87 in.) C 94.5 mm (3.72 in.) D 58.2 mm (2.29 in.)
E
Evap Connection
Point
F
4 X 5/16-18
UNC-2B in.
16.5 mm (0.649 in.)
Deep No Studs
G 30° H
50 mm (1.97 in.)
Exhaust Port #2
I 262.8 mm (10.35 in.) J 104 mm (4.10 in.) K 242.3 mm (9.54 in.) L 89.8 mm (3.54 in.)
M
18 mm (0.71 in.)
Oil Filter Removal
N 116.8 mm (4.60 in.) O Mounting Hole "A" P Rotation Direction
Q 45° R 35° S
4 X 9.005 mm (0.355
in.)
37 mm (1.46 in.)
Deep on a Ø
254 mm (10.0 in.)
B.C.
T
312.0 mm (12.28 in.)
Throttle and Choke
Cable Mounting
Surface
U
50 mm (1.97 in.)
Exhaust Port #1
