Specifi cations
16 690 07 Rev. -- KohlerEngines.com
Engine Dimensions-with Heavy-Duty Air Cleaner-Valve Cover Side
A
B
C
D
A 87.6 mm (3.45 in.) B
Engine Mounting
Surface
C 152.9 mm (6.02 in.) D Mounting Hole "A"
