THREADED COUNTERFLANGES KIT (FTHREADED COUNTERFLANGES KIT (F
THREADED COUNTERFLANGES KIT (FTHREADED COUNTERFLANGES KIT (F
THREADED COUNTERFLANGES KIT (F
, N, R, N, R
, N, R, N, R
, N, R
, G SV) EN 1092-1, G SV) EN 1092-1
, G SV) EN 1092-1, G SV) EN 1092-1
, G SV) EN 1092-1
CODICI KIT CONTROFLANGE TONDE FILETTATE per SV
PUMP
P.NUMBER DESCRIPTION TYPE DN ø C ø A B ø D H ø F N° PN
109398000 KIT RP1" PN25 GALVANIZED STEEL 1-3SV 25 Rp 1 85 10 115 16 14 4 25
109398002 KIT RP1" PN25 AISI 316 1-3SV 25 Rp 1 85 10 115 16 14 4 25
109398010 KIT RP1"1/4 PN25 GALVANIZED STEEL 5SV 32 Rp 1¼ 100 13 140 16 18 4 25
109398012 KIT RP1"1/4 PN25 AISI 316 5SV 32 Rp 1¼ 100 13 140 16 18 4 25
109398020 KIT RP1"1/2 PN25 GALVANIZED STEEL 10SV 40 Rp 1½ 110 14 150 19 18 4 25
109398022 KIT RP1"1/2 PN25 AISI 316 10SV 40 Rp 1½ 110 14 150 19 18 4 25
109398030 KIT RP2" PN25 GALVANIZED STEEL 15-22SV 50 Rp 2 125 16 165 24 18 4 25
109398032 KIT RP2" PN25 AISI 316 15-22SV 50 Rp 2 125 16 165 24 18 4 25
109392710 KIT RP2"1/2 PN16 GALVANIZED STEEL 33SV 65 Rp 2½ 145 16 185 23 18 4 16
109392750 KIT RP2"1/2 PN16 AISI 316 33SV 65 Rp 2½ 145 16 185 23 18 4 16
109392720 KIT RP3" PN16 GALVANIZED STEEL 46SV 80 Rp 3 160 17 200 27 18 8 16
109392760 KIT RP3" PN16 AISI 316 46SV 80 Rp 3 160 17 200 27 18 8 16
109392730 KIT RP4" PN16 GALVANIZED STEEL 66SV-92SV 100 Rp 4 180 18 220 31 18 8 16
109392770 KIT RP4" PN16 AISI 316 66SV-92SV 100 Rp 4 180 18 220 31 18 8 16
kit_flg_fil-en_a_td
DIMENSIONS (mm) HOLES
Kit containing 2 counterflanges with bolts and gaskets.
- threaded, galvanized steel (F, R, G versions).
- threaded, AISI 316L stainless steel (N versions).
