Description
12 EN 11|2018
3 Description
Fig. 2
(
1
)
Suction dischar
g
e
(
3
)
Motor
(
2
)
Pressure dischar
g
e
(
4
)
Outer pump casin
g
(
5
)
Drive lantern
3.1 Function
The pump primes the pumped fluid via the suction discharge (1). The pumped fluid is pumped upwards
via the stages consisting of impellers and diffusers. This is then pumped between the stages and the
outer pump casing to the outside of the pump and via the pressure discharge (2) into the pressure line.
The strainer basket, if applicable, filters out rough contaminations. The motor’s (3) drive shaft is fixed to
the pump shaft. The motor (3) is attached to the pump via the drive lantern (5).
3.2 Designation
Example: IN-VB 85-20-1 F
Code Description
IN Series
VB VB
Pump housing and hydraulic made from stainless steel V2A
VB-S
Pump housing and hydraulic made from stainless steel V4A
F
T
y
pe of connection:
Without identification: Oval flan
g
e
F Round flan
g
e
V Victaulic couplin
g
85
Construction size, flow rate [m³/h] in Q
opt
.
2, 4, 6, 10, 15, 25, 40, 60, 85, 125
20 Number of impellers
(
2 pcs
)
-1 Reduced impeller
CL VB-CL Pump housing made from cast iron with low NPSH level and
pump h
y
draulics made from stainless steel V2A.
