Faults
26 EN 11|2018
Fault: Pump doesn’t run.
Possible cause Solution
No stress on the terminal clamps.
Check the power supply (power circuit, main switch,
fuse).
Check the motor protection switch and residual
current device.
Motor protection triggered.
Check whether the correct value is set. The correct
value (I
nenn
) can be found on the motor name plate.
Reset the motor protection switch if necessary.
Should the problem persist, contact an electrician.
Fault: No flow rate; motor turns
Possible cause Solution
Pump shaft is faulty. Replace shaft and seals.
Coupling is loose.
Tighten the connecting screws with the
recommended torque.
Fault: Too low a flow rate and/or dynamic head
Possible cause Solution
Suction and/or pressure valve is closed.
Open shut-off valves.
Air in the pump/pipe. Ventilate pump.
Assemble the suction line rising towards the pump.
Little or no intake. Increase intake pressure.
Incorrect direction of rotation (3~). Swap L1 and L2 in the three-phase power supply.
Suction line not ventilated.
Ventilate the suction line.
Pump is priming air due to a leak in the
suction line.
Maintain suction line.
The diameter of the suction line is too
small.
Increase the diameter of the suction line.
Too little flow rate in the water meter in
the suppl
y
line.
Increase water meter.
Foot valve is blocked. Clean foot valve.
Pump/pump parts blocked due to
impurities.
Clean pump and pump parts.
O-Ring isn‘t resistant to the pumped
fluid.
Use an O-ring made from a suitable material.
Fault: Pump turns in the opposite direction after being turned off
Possible cause Solution
Leak in the suction line.
Repair or replace riser.
Faulty foot valve or non-return valve.
Replace components.
Foot valve blocked in an open position.
Clean or replace.
