8
EN
e) Do not use worn down wheels from larger power tools . Wheel
intended for larger power tool is not suitable for the higher speed of a
smaller tool and may burst.
Additional Safety Warnings Specific for Abrasive Cutting-off
Operations:
a) Do not “jam” the cut-off wheel or apply excessive pressure .Do not
attempt to make an excessive depth of cut. Overstressing the wheel
increases the loading and susceptibility to twisting or binding of the
wheel in the cut and the possibility of kickback or wheel breakage.
b) Do not position your body in lime with and behind the rotating wheel.
When the wheel, at the point of operation, is moving away from your body ,
the possible kickback may propel the spinning wheel and the power tool
directly at you .
c) When wheel is binding or when interrupting a cut for any reason,
switch off the power tool and hold the power tool motionless until
the wheel comes to a complete stop. Never attempt to remove the
cut-off wheel from the cut while the wheel is in motion otherwise
kickback may occur. Investigate and take corrective action to eliminate
the cause of wheel binding.
d) Do not restart the cutting operation in the workpiece . Let the wheel
reach full speed and carefully the cut. The wheel may bind, walk up or
kickback if the power tool is restarted in the workpiece.
e) Support panels or any oversized workpiece to minimize the of wheel
pinching and kickback. Large workpieces tend to sag under their own
weight. Supports must be placed under the workpiece near the line of cut
and near the edge of the workpiece on both sides of the wheel.
f) Use extra caution when making a “pocket cut ” into existing walls or
other blind areas . The protruding wheel may cut gas or water pipes,
electrical wiring or objects that can cause kickback.
INTRODUCTION
This tool is intended for grinding, cutting and de burring metal materials
without the use of water.
Do not apply pressure on the tool; let the speed of the cutting disc do the
work Cutting operations with bonded abrasive cut-off wheels are only
allowed when a cut-off guard is used.
READ AND SAVE THIS INSTRUCTION MANUAL
2. SAFETY INSTRUCTIONS FOR ANGLE GRINDERS
FUNCTIONAL DESCRIPTION
This angle grinder has been designed for industrial grinding and cutting applications.
Please refer to Figure 1 to familiarize yourself with the major
1. Auxiliary handle
2. Spindle lock button
3. Ventilation slots
4. On/off switch trigger
5. Threads (for auxiliary handle)
6. Grinding guard
7. Inner flange
8. Grinding disc
9. Outer flange
10. Spanner
11. Rotate button (except SA150)
12. Lock off button
3. FUNCTIONAL DESCRIPTION
4. ASSEMBLY
ASSEMBLY
INSTALL THE GRINDING WHEEL (Fig. 2)
1. Depress and hold the spindle lock (2).
2. Remove the outer flange (9) with a spanner (10) in the direction of anticlockwise.
3. Place the grinding wheel (8) over the spindle with the depressed center against
the inner flange (7).
4. Press the spindle lock (2) again, insert the outer flange (9) and securely tighten
with a spanner (10), but don’t overtighten it.
Allow the angle grinder to run in idle for least a minute with the grinding or cutting
disc correctly assembled, vibration disc should be immediately replaced.
INSTALL THE SIDE HANDLE
Insert the side handle on either side of the angle grinder by turning it clockwise
depending on the operator’s preference.
ROTATE REAR HANDLE ( except SA150) (Fig.3)
- Push in the button (11).
- The rear handle can now be turned 90° to both sides and can be engaged.
Always unplug the tool before assembly and adjustment.
TO INSTALLATION GUARD:
Open guard release/lock latch, and position guard on spindle neck so that the two
bumps on guard, line up with the two notches on the spindle neck. Rotate guard
either direction to desired position, and close latch ti secure guard in place.
WARNING! The product is equipped with a protective casing,
designed for grinding discs. For work cutting disc must purchase
and install the product on a special closed on both sides housing,
appropriate safety standards EN 60745 - 2 - 3.
Operation of the unit with removed protective cover is strictly
prohibited! Before starting work, check the reliability of fixing guard.
The position of the guard can be adjusted to accommodate the operation being
performed. To attach wheel guard DISCONNECT tool from power source.
WHEEL GUARD INSTALLATION (Fig. 4)
EN
9
TO REMOVE GUARD:
Open guard release/lock latch, rotate guard until the two bumps on guard line up
with the two notches on the spindle neck, and lift guard off the spindle neck.
.
