Manually specify the gateway address.

• Default: 0.0.0.0

IPv6 Stateless Setting

Select whether to enable or disable IPv6.

• Active

• Inactive

• Default: Active

NW Frame Type

Specify the frame type for NetWare.

• Auto Select

• Ethernet II

• Ethernet 802.2

• Ethernet 802.3

• Ethernet SNAP

• Default: Auto Select

Effective Protocol

Specify the effective protocol.

• IPv4

Active, Inactive

• Default: Active

• IPv6

Active, Inactive

• Default: Inactive

• NetWare

Active, Inactive

• Default: Active

5. Making Printer Settings Using the Control Panel

194
