• SMB
Active, Inactive
• Default: Active
• AppleTalk
Active, Inactive
• Default: Active
Ethernet Speed
Specify the network speed to operate the printer.
• Auto Select
• 10Mbps Half Duplex
• 10Mbps Full Duplex
• 100Mbps Half Duplex
• 100Mbps Full Duplex
• Default: Auto Select
LAN Type
Select Ethernet or IEEE 802.11b wireless LAN.
• Ethernet
• IEEE 802.11b
• Default: Ethernet
• This menu appears only when the optional 802.11b interface unit is installed.
IEEE 802.11b
Configure settings for wireless LAN. This menu appears only when the optional 802.11b inter-
face unit is installed.
Communication Mode
Specify the transmission mode for IEEE 802.11b.
• 802.11 Ad hoc
• Infrastructure
• Ad hoc
Host Interface Menu
195
5
