STANDARD RECOVERY RECTIFIERS
1N4001 - 1N4007
DO-41 (Plastic)
Axial Lead Plastic
Package
These Axial Lead Mounted Rectifiers are used for General-Purpose Low-Power Applications
ABSOLUTE MAXIMUM RATINGS (T
a
=25ºC)
SYMBOL
1N
4001
1N
4002
1N
4003
1N
4004
4005
1N
4006
1N
4007
UNIT
V
RRM
V
RWM
V
R
50 100 200 400 600 800 1000 V
V
RSM
60 120 240 480 720 1000 1200 V
V
R(RMS)
35 70 140 280 420 560 700 V
I
O
1.0 A
I
FSM
30 A
R
th (j-a)
50 ºC/W
StorageTemperature Range
T
stg
- 55 to +150 ºC
Operating Junction Temperature
T
j
-55 to +125 ºC
ELECTRICAL CHARACTERISTICS (T
a
=25ºC unless specified otherwise )
SYMBOL UNIT
V
F
V
V
F(AV)
V
I
R
µA
µ
A
I
R(AV)
µA
C
j
pF
1N4001_1N4007Rev030103E
Junction Capacitance
V
R
= 4V, f = 1MHz
typ 15
Maximum Full-Cycle Average Reverse Current
Maximum Full-Cycle Average Forward
Voltage Drop
I
O
=1.0A, T
a
=75ºC
0.8
I
O
=1.0A, T
a
=75ºC
30
1.1
Maximum Reverse Current
@ rated V
R
T
a
= 25ºC
T
a
= 100ºC
5
500
Maximum Instantaneous Forward Voltage
Drop
MAX
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blockng Voltage
Non-Repetitive Peak Reverse Voltage
(halfwave, single phase, 60Hz)
RMS Reverse Voltage
Average Rectified Current
0.375 " lead length @ T
a
=75ºC
Non-Repetitive Peak Surge Current 8.3ms
single half sine-wave superimposed on rated
load
I
F
= 1.0A
DESCRIPTION
DESCRIPTION TEST CONDITION
Thermal Resistance from Junction to Ambient
in free air
Continental Device India Limited
Data Sheet Page 1 of 3
Continental Device India Limited
An ISO/TS 16949, ISO 9001 and ISO 14001 Certified Company
