- 21 -

Hardware Installation

1-7 Back Panel Connectors

Q-Flash Plus Button

(Note)

This button allows you to update the BIOS when the power connector is connected but the system is not

powered on.

Clear CMOS Button

UsethisbuttontocleartheCMOSvalues(e.g.BIOSconguration)andresettheCMOSvaluestofactory

defaults when needed.

• Whenremovingthecableconnectedtoabackpanelconnector,rstremovethecablefromyour

device and then remove it from the motherboard.

• When removing the cable, pull it straight out from the connector. Do not rock it side to side to

prevent an electrical short inside the cable connector.

• Always turn off your computer and unplug the power cord from the power outlet before using

the clear CMOS button.

• Do not use the clear CMOS button when the system is on, or the system may shutdown and

data loss or damage may occur.

• After system restart, go to BIOS Setup to load factory defaults (select Load Optimized Defaults) or

manuallyconguretheBIOSsettings(refertoChapter2,"BIOSSetup,"forBIOScongurations).

SMA Antenna Connectors (2T2R)

Use this connector to connect an antenna.

Tighten the antenna cables to the antenna connectors and then move the antenna to a place

where the signal is good.

USB 2.0/1.1 Port

TheUSBportsupportstheUSB2.0/1.1specication.UsethisportforUSBdevices.

USB 3.2 Gen 1 Port

TheUSB3.2Gen1portsupportstheUSB3.2Gen1specicationandiscompatibletotheUSB2.0

specication.UsethisportforUSBdevices.

USB 3.2 Gen 1 Port (White)

TheUSB3.2Gen1portsupportstheUSB3.2Gen1specicationandiscompatibletotheUSB2.0

specication.UsethisportforUSBdevices.BeforeusingQ-FlashPlus

(Note)

, make sure to insert the USB

ashdriveintothisportrst.

RJ-45 LAN Port (LAN2)

The Gigabit Ethernet LAN port provides Internet connection at up to 2.5 Gbps data rate. The following

describes the states of the LAN port LEDs.

(Note) To enable Q-Flash Plus function, refer to Chapter 5, "Unique Features," for more information.

Activity LED

Connection/

Speed LED

LAN Port

Activity LED:Connection/Speed LED:

State Description

Orange 2.5 Gbps data rate

Green 1 Gbps data rate

Off 100/10 Mbps data rate

State Description

Blinking Data transmission or receiving is occurring

Off No data transmission or receiving is occurring
