Gigabyte X570 AORUS MASTER (rev. 1.1/1.2) [87/104] 1 2 configuring s pdif out

- 87 -

Appendix

The S/PDIF Out jack can transmit audio signals to an external decoder for decoding to get the best audio quality.

1. Connecting a S/PDIF Out Cable:

Connect a S/PDIF optical cable to an external decoder for transmitting the S/PDIF digital audio signals.

Connects to a S/PDIF optical cable

6-1-2 ConguringS/PDIFOut

Step 2:

On the Playback tab, make sure your headphone is set

as the default playback device. For the device connected

to the Line out jack on the back panel, right-click on

Speakers and select Set as Default Device; for the

device connected to the Line out jack on the front panel,

right-click on Realtek HD Audio 2nd output.

2. Configuring S/PDIF Out:

On the Realtek Digital Output screen, Select the sample

rate and bit depth in the Default Format section.
