Gigabyte X570 AORUS MASTER (rev. 1.1/1.2) [68/104] 2 application software

Drivers Installation

- 68 -

4-3 Information

This page provides detailed information on the drivers on the driver disk. The Contact page provides

contact information of the GIGABYTE Taiwan headquarter. You can click the URL on this page to link to the

GIGABYTEwebsitetocheckmoreinformationontheGIGABYTEheadquarterorworldwidebranchofces.

4-2 Application Software

This page displays the apps that GIGABYTE develops and some free software. You can select the apps

you want and click the Install icon to begin the installation.
