- 22 -
2-2 The Main Menu
Classic Setup Function Keys
<
f
><
g
>
Move the selection bar to select a setup menu
<
h
><
i
>
Movetheselectionbartoselectancongurationitemonamenu
<Enter>
Execute command or enter a menu
<
+
>/<Page Up>
Increase the numeric value or make changes
<
-
>/<Page Down>
Decrease the numeric value or make changes
<F1>
Show descriptions of the function keys
<F2>
Switch to Easy Mode
<F5>
RestorethepreviousBIOSsettingsforthecurrentsubmenus
<F7>
LoadtheOptimizedBIOSdefaultsettingsforthecurrentsubmenus
<F8>
Access the Q-Flash utility
<F9>
Display system information
<F10>
Save all the changes and exit the BIOS Setup program
<F12>
Capture the current screen as an image and save it to your USB drive
<Esc> Main Menu: Exit the BIOS Setup program
Submenus: Exit current submenu
Hardware
Information
CongurationItems Current Settings
Setup Menus
System Time
Quick Access Bar allows you to enter Easy Mode, select
BIOSdefaultlanguage,congurefansettings,orenter
Q-Flash.
