Gigabyte H370M D3H GSM (rev. 1.0) [41/48] C 2 uefiraidconfiguration

PleasevisitGIGABYTE'swebsitefordetailsonconguringaRAIDarray.

C-2.UEFIRAIDConguration

OnlyWindows10/8.164-bitsupportsUEFIRAIDconguration.

Step:

1. In BIOS Setup, go to BIOS and set CSM Support to Disabled. Save the changes and exit BIOS Setup.

2. After the system reboot, enter BIOS Setup again. Then enter the Peripherals\Intel(R) Rapid Storage

Technology sub-menu.

3. On the Intel(R) Rapid Storage Technology menu, press <Enter> on Create RAID Volume to enter the

Create RAID Volumescreen.Enteravolumenamewith1~16letters(letterscannotbespecialcharacters)

under the Nameitemandpress<Enter>.Then,selectaRAIDlevel.RAIDlevelssupportedincludeRAID

0,RAID1,RAID10,andRAID5(theselectionsavailabledependonthenumberoftheharddrivesbeing

installed).Next,usethedownarrowkeytomovetoSelect Disks.

4. Under Select Disksitem,selecttheharddrivestobeincludedintheRAIDarray.Pressthe<Space>key

ontheharddrivestobeselected(selectedharddrivesaremarkedwith"X").Thensetthestripeblocksize.

Thestripeblocksizecanbesetfrom4KBto128KB.Onceyouhaveselectedthestripeblocksize,setthe

volume capacity.

5. After setting the capacity, move to Create Volume and press <Enter> to begin.

6. After completing, you'll be brought back to the Intel(R) Rapid Storage Technology screen. Under RAID

VolumesyoucanseethenewRAIDvolume.Toseemoredetailedinformation,press<Enter>onthevolume

tocheckforinformationonRAIDlevel,stripeblocksize,arrayname,andarraycapacity,etc.

C-3.ConguringLegacyRAIDROM

Enter the Intel

legacyRAIDBIOSsetuputilitytocongureaRAIDarray.Skipthisstepandproceedwiththe

installationofWindowsoperatingsystemforanon-RAIDconguration.

Step:

1. In BIOS Setup, go to BIOS and set CSM Support to Enabled and Storage Boot Option Control to Legacy.

Save the changes and exit BIOS Setup. After the POST memory test begins and before the operating system

bootbegins,lookforamessagewhichsays"Press<Ctrl-I>toenterCongurationUtility".Press<Ctrl>+<I>

toentertheRAIDCongurationUtility.

2. After you press <Ctrl> + <I>, the MAIN MENUscreenwillappear.IfyouwanttocreateaRAIDarray,select

Create RAID Volume in MAIN MENU and press <Enter>.

3. After entering the CREATE VOLUME MENUscreen,enteravolumenamewith1~16letters(letterscannot

be special characters) under the Nameitemandpress<Enter>.Then,selectaRAIDlevel.RAIDlevels

supportedincludeRAID0,RAID1,RAID10,andRAID5(theselectionsavailabledependonthenumberof

the hard drives being installed). Press <Enter> to proceed.

4. Under Disksitem,selecttheharddrivestobeincludedintheRAIDarray.Ifonlytwoharddrivesareinstalled,

theywillbeautomaticallyassignedtothearray.Setthestripeblocksizeifnecessary.Thestripeblocksize

canbesetfrom4KBto128KB.Onceyouhaveselectedthestripeblocksize,press<Enter>.

5. Enter the array capacity and press <Enter>. Finally press <Enter> on the Create Volume item to begin

creatingtheRAIDarray.Whenpromptedtoconrmwhethertocreatethisvolume,press<Y>toconrmor

<N>tocancel.

6. Whencompleted,youcanseedetailedinformationabouttheRAIDarrayintheDISK/VOLUME INFORMATION

section,includingtheRAIDlevel,stripeblocksize,arrayname,andarraycapacity,etc.ToexittheRAID

BIOS utility, press <Esc> or select 6. Exit in MAIN MENU.
