Storage Interface - SupportforRAID0,RAID1,RAID5,andRAID10
* Referto"1-7InternalConnectors,"fortheinstallationnoticesfortheM.2andSATA
connectors.
Intel
®
Optane
™
MemoryReady
USB Chipset:
- 1 x USB Type-C
™
port on the back panel, with USB 3.1 Gen 2 support
- 1 x USB 3.1 Gen 2 Type-A port (red) on the back panel
- 6 x USB 3.1 Gen 1 ports (4 ports on the back panel, 2 ports available through
the internal USB header)
- 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through
the internal USB headers)
* The CNViconnector shares bandwidth with the F_USB2 header.When a Wi-Fi
moduleispopulatedintheCNViconnector,oneoftheUSB2.0/1.1portsroutedto
theF_USB2headerbecomesunavailable.
Internal
Connectors
1 x 24-pin ATX main power connector
1x8-pinATX12Vpowerconnector
2 x M.2 Socket 3 connectors
6 x SATA 6Gb/s connectors
1 x CPU fan header
3 x system fan headers
1xRGBLEDstripheader
1 x front panel header
1 x front panel audio header
1 x S/PDIF Out header
1 x USB 3.1 Gen 1 header
2 x USB 2.0/1.1 headers
1xTrustedPlatform Module(TPM) header(2x6 pin, forthe GC-TPM2.0_S
module only)
1 x serial port header
1 x parallel port header
1 x Clear CMOS jumper
Back Panel
Connectors
1 x PS/2 keyboard/mouse port
1 x D-Sub port
1xDVI-Dport
1 x HDMI port
1 x USB Type-C
™
port, with USB 3.1 Gen 2 support
1 x USB 3.1 Gen 2 Type-A port (red)
4 x USB 3.1 Gen 1 ports
2 x USB 2.0/1.1 ports
1xRJ-45port
6 x audio jacks
I/O Controller iTE
®
I/O Controller Chip
- 7 -
