TECHNICAL SPECIFICATIONS
EWAQ F-XS
200
220
250
310
350
360
320
170
MODEL
Capacity - Cooling (1) kW 356 316 356 316 244 194 170 220
Capacity control - Type
---
Step
Step
Step
Step
Step
Step
Step
Step
Capacity control - Minimum capacity % 25.0 23.0 25.0 23.0 22.0 21.0 25.0 25.0
Unit power input - Cooling (1)
kW
115
102
115
102
78.3
62.2
54.8
70.6
EER (1)
---
3.09
3.09
3.09
3.09
3.12
3.13
3.11
3.12
ESEER --- 4.33 4.30 4.06 4.05 4.03 4.08 3.89 3.91
IPLV
---
4.80
4.60
4.65
4.68
4.63
4.73
4.55
4.63
CASING
Colour (2)
---
IW
IW
IW
IW
IW
IW
IW
IW
Material (2) --- GPSS GPSS GPSS GPSS GPSS GPSS GPSS GPSS
DIMENSIONS
Height
mm
2221
2221
2271
2271
2271
2271
2271
2271
Width mm 2258 2258 1224 1224 1224 1224 1224 1224
Length
mm
3210
3210
6213
6213
5313
4413
4413
5313
WEIGHT
Unit Weight
kg
2732
2600
2632
2500
2339
1958
1688
2210
Operating Weight kg 2772 2514 2672 2514 2353 1973 1700 2225
WATER HEAT EXCHANGER
Type (3)
---
PHE
PHE
PHE
PHE
PHE
PHE
PHE
PHE
Water Volume l 40 14 40 14 14 14 12 14
Nominal water flow rate - Cooling
l/s
17.0
15.1
17.0
15.1
11.7
9.3
8.2
10.5
Nominal Water pressure drop - Cooling kPa 23 22 23 22 42 27 25 34
Insulation material (4)
CC
CC
CC
CC
CC
CC
CC
CC
AIR HEAT EXCHANGER
Type (5) --- HFP HFP HFP HFP HFP HFP HFP HFP
FAN
Type (6) --- DPT DPT DPT DPT DPT DPT DPT DPT
Drive (7)
---
DOL
DOL
DOL
DOL
DOL
DOL
DOL
DOL
Diameter mm 800 800 800 800 800 800 800 800
Nominal air flow
l/s
30245
31722
30245
31722
25204
21148
21845
26874
Quantity
No.
6
6
6
6
5
4
4
5
Speed rpm 900 900 900 900 900 900 900 900
Motor input
kW
10.5
10.5
10.5
10.5
8.8
7.0
7.0
8.8
COMPRESSOR
Type
---
Scroll
Scroll
Scroll
Scroll
Scroll
Scroll
Scroll
Scroll
Oil charge l 25 26 25 26 23 16 13 19
Quantity No. 4 4 4 4 4 4 4 4
SOUND LEVEL
Sound Power - Cooling dB(A) 96 96 96 96 95 93 91 94
Sound Pressure - Cooling (8)
dB(A)
77
77
76
76
76
74
72
75
REFRIGERANT CIRCUIT
Refrigerant type
---
R410A
R410A
R410A
R410A
R410A
R410A
R410A
R410A
Refrigerant charge kg 24 24 24 24 21 18 14 18
N. of circuits No. 2 2 2 2 2 2 2 2
PIPING CONNECTIONS
Evaporator water inlet/outlet 3" 3" 3" 3" 3" 3" 3" 3"
Fluid: Water
(1) Cooling capacity, unit power input in cooling and EER are based on the following conditions: evaporator 12.0/7.0°C; ambient 35.0°C, unit at full load
operation;
(2) IW: Ivory White; GPSS: Galvanized and Painted Steel Sheet; (3) PHE: Plate Heat Exchanger --- S&T: Single Pass Shell & Tube
(4) CC: Closed Cell; (5) HFP: High efficiency fin and tube type with integral subcooler
(6) DPT: Direct Propeller Type; (7) DOL: Direct On Line - VFD: Inverter - BRS: Brushless
(8) The values are according to ISO 3744 and are referred to: evaporator 12/7°C, ambient 35°C, full load operation.
