ELECTRICAL SPECIFICATIONS
EWAQ F-XL
200 220 250 310 350 360 320 170 MODEL
POWER SUPPLY
Phases Nr 3 3 3 3 3 3 3 3
Frequency
Hz
50
50
50
50
50
50
50
50
Voltage V 400 400 400 400 400 400 400 400
Voltage tolerance Minimum % -10% -10% -10% -10% -10% -10% -10% -10%
Voltage tolerance Maximum
%
+10%
+10%
+10%
+10%
+10%
+10%
+10%
+10%
UNIT
Maximum starting current A 281 338 353 408 480 509 480 509
Nominal running current cooling
A
110
117
128
141
181
202
181
202
Mximum running current
A
138
149
164
180
229
258
229
258
Maximum current for wires sizing A 151 164 181 198 251 284 251 284
FANS
Nominal running current cooling
A
16
16
20
20
24
24
24
24
COMPRESSORS
Phases Nr 3 3 3 3 3 3 3 3
Voltage V 400 400 400 400 400 400 400 400
Voltage tolerance Minimum
%
-10%
-10%
-10%
-10%
-10%
-10%
-10%
-10%
Voltage tolerance Maximum % +10% +10% +10% +10% +10% +10% +10% +10%
Maximum running current
A
61
61
66
66
72
72
80
80
102
102
117
117
102
102
117
117
Starting method --- DOL DOL DOL DOL DOL DOL DOL DOL
EWAQ F-XL
430
450
520
610
680
400
MODEL
POWER SUPPLY
Phases
Nr
3
3
3
3
3
3
Frequency
Hz
50
50
50
50
50
50
Voltage V 400 400 400 400 400 400
Voltage tolerance Minimum
%
-10%
-10%
-10%
-10%
-10%
-10%
Voltage tolerance Maximum % +10% +10% +10% +10% +10% +10%
UNIT
Maximum starting current A 629 643 657 642 768 818
Nominal running current cooling
A
229
240
254
300
343
379
Mximum running current A 294 308 322 391 433 482
Maximum current for wires sizing
A
323
338
354
430
476
530
FANS
Nominal running current cooling
A
32
32
32
40
40
48
COMPRESSORS
Phases Nr 3 3 3 3 3 3
Voltage
V
400
400
400
400
400
400
Voltage tolerance Minimum % -10% -10% -10% -10% -10% -10%
Voltage tolerance Maximum % +10% +10% +10% +10% +10% +10%
Maximum running current A
131
131
131
145
145
145
175
175
189
203
217
217
Starting method --- DOL DOL DOL DOL DOL DOL
Fluid: Water
Allowed voltage tolerance ± 10%. Voltage unbalance between phases must be within ± 3%.
Maximum starting current: starting current of biggest compressor + current of the other compressors at maximum load + fans current at maximum load
Nominal current in cooling mode is referred to the following conditions: evaporator 12/7°C; ambient 35°C; compressors + fans current.
Maximum running current is based on max compressor absorbed current in its envelope and max fans absorbed current
Maximum unit current for wires sizing is based on minimum allowed voltage
Maximum current for wires sizing: (compressors full load ampere + fans current) x 1,1.
