OPTIONS
Standard Options (supplied on basic unit)
Direct on line starter (DOL)
Double setpoint - Dual leaving water temperature setpoints.
Evaporator victaulic kit - Hydraulic joint with gasket for an easy and quick water connection.
20mm evaporator insulation - The external shell is covered with a 20mm closed cell insulation material.
Evaporator electric heater - Electric heater (controlled by a thermostat) to protect the evaporator from freezing down to -
28°C
ambient temperature, providing the power supply is on.
Evaporator flow switch - Supplied separately to be wired and installed on the evaporator water piping (by the customer).
Electronic expansion valve
Ambient outside temperature sensor and setpoint reset
Hour run meter
General fault contactor
Main switch interlock door
Water filter - The water filter removes impurities from water by means of a fine physical barrier.
Options (on request)
MECHANICAL
Partial heat recovery - Produced with plate to plate heat exchangers to produce hot water.
Brine version - Allows the unit to operate down to -8°C leaving liquid temperature (antifreeze required).
Axial fans (250 Pa lift)
Condenser coil guards
Evaporator area guards
Cu-Cu condenser coil - To give better protection against corrosion by aggressive environments.
Cu-Cu-Sn condenser coil - To give better protection against corrosion in aggressive environments and by salty air.
Alucoat fins coil - Fins are protected by a special acrylic paint with a high resistance to corrosion.
Discharge line shut-off valve - Installed on the discharge port of the compressor to facilitate maintenance operation.
Suction line shut-off valve - Installed on the suction port of the compressor to facilitate maintenance operation.
High pressure side manometers
Low pressure side manometers
One centrifugal pump (low lift) - Hydronic kit consists of: single direct driven centrifugal pump, water filling system with pressure
gauge, safety valve, drain valve. The motor pump is protected by a circuit breaker installed in control panel. The kit is ass
embled and
wired to the control panel. The pipe and pump are protected from freezing with an additional electrical heater.
One centrifugal pump (high lift) Hydronic kit consists of: single direct driven centrifugal pump, water filling system with pressure
gauge, safety valve, drain valve. The motor pump is protected by a circuit breaker installed in control panel. The kit is a
ssembled and
wired to the control panel. The pipe and pump are protected from freezing with an additional electrical heater.
Two centrifugal pump (low lift) - Hydronic kit consists of: twin direct driven centrifugal pumps, water filling system with pressure
gauge, safety valve, drain valve. The motor pump is protected by a circuit breaker installed in control panel. The kit is ass
embled and
wired to the control panel. The pipe and pumps are protected from freezing with an additional electrical heater.
Two centrifugal pump (high lift) Hydronic kit consists of: twin direct driven centrifugal pumps, water filling system with pressure
gauge, safety valve, drain valve. The motor pump is protected by a circuit breaker installed in control panel. The kit is assembl
ed and
wired to the control panel. The pipe and pumps are protected from freezing with an additional electrical heater.
Double pressure relief valve with diverter
ELECTRICAL / CONTROL
