TECHNICAL SPECIFICATIONS
EWAQ F-XR
410
430
500
580
650
390
MODEL
Capacity - Cooling (1) kW 645 579 502 407 385 433
Capacity control - Type
---
Step
Step
Step
Step
Step
Step
Capacity control - Minimum capacity % 17.0 14.0 17.0 20.0 21.0 25.0
Unit power input - Cooling (1)
kW
219
200
170
136
128
146
EER (1)
---
2.95
2.90
2.96
2.99
3.01
2.96
ESEER --- 4.54 4.63 4.75 4.62 4.65 4.53
IPLV
---
5.05
5.08
5.05
4.88
5.01
4.98
CASING
Colour (2)
---
IW
IW
IW
IW
IW
IW
Material (2) --- GPSS GPSS GPSS GPSS GPSS GPSS
DIMENSIONS
Height
mm
2221
2221
2221
2221
2221
2221
Width mm 2258 2258 2258 2258 2258 2258
Length
mm
5910
5010
5010
4110
4110
4110
WEIGHT
Unit Weight
kg
4655
4228
4120
3280
3168
3298
Operating Weight kg 4716 4288 4166 3326 3208 3344
WATER HEAT EXCHANGER
Type (3)
---
PHE
PHE
PHE
PHE
PHE
PHE
Water Volume l 60 60 46 46 40 46
Nominal water flow rate - Cooling
l/s
30.9
27.7
24.0
19.5
18.4
20.7
Nominal Water pressure drop - Cooling kPa 51 40 38 26 28 27
Insulation material (4)
CC
CC
CC
CC
CC
CC
AIR HEAT EXCHANGER
Type (5) --- HFP HFP HFP HFP HFP HFP
FAN
Type (6) --- DPT DPT DPT DPT DPT DPT
Drive (7)
---
DOL
DOL
DOL
DOL
DOL
DOL
Diameter mm 800 800 800 800 800 800
Nominal air flow
l/s
46852
39044
39044
31235
32570
31235
Quantity
No.
12
10
10
8
8
8
Speed rpm 705 705 705 705 705 705
Motor input
kW
9.0
7.5
7.5
6.0
6.0
6.0
COMPRESSOR
Type
---
Scroll
Scroll
Scroll
Scroll
Scroll
Scroll
Oil charge l 38 38 38 25 25 25
Quantity No. 6 6 6 4 4 4
SOUND LEVEL
Sound Power - Cooling dB(A) 92 90 89 89 89 90
Sound Pressure - Cooling (8)
dB(A)
71
70
69
70
69
70
REFRIGERANT CIRCUIT
Refrigerant type
---
R410A
R410A
R410A
R410A
R410A
R410A
Refrigerant charge kg 46 40 40 35 35 35
N. of circuits No. 2 2 2 2 2 2
PIPING CONNECTIONS
Evaporator water inlet/outlet 3" 3" 3" 3" 3" 3"
Fluid: Water
(1) Cooling capacity, unit power input in cooling and EER are based on the following conditions: evaporator 12.0/7.0°C; ambient 35.0°C, unit at full load
operation;
(2) IW: Ivory White; GPSS: Galvanized and Painted Steel Sheet; (3) PHE: Plate Heat Exchanger --- S&T: Single Pass Shell & Tube
(4) CC: Closed Cell; (5) HFP: High efficiency fin and tube type with integral subcooler
(6) DPT: Direct Propeller Type; (7) DOL: Direct On Line - VFD: Inverter - BRS: Brushless
(8) The values are according to ISO 3744 and are referred to: evaporator 12/7°C, ambient 35°C, full load operation.
