Gigabyte GA-78LMT-USB3 R2 (rev. 1.0) [17/35] 1 startup screen
![Gigabyte GA-78LMT-USB3 R2 (rev. 1.0) [17/35] 1 startup screen](/views2/1669478/page17/bg11.png)
- 17 -
2-1 Startup Screen
The following screens may appear when the computer boots.
(Sample BIOS Version: E2)
The POST Screen
• If you do not nd the settings you want in the Main Menu or a submenu, press <Ctrl>+<F1> to access more
advanced options.
• When the system is not stable as usual, select the Load Optimized Defaults item to set your system to its defaults.
• The BIOS Setup menus described in this chapter are for reference only and may differ by BIOS version.
On the main menu of the BIOS Setup program, press arrow keys to move among the items and press <Enter>
to accept or enter a sub-menu. Or you can use your mouse to select the item you want.
Motherboard Model
BIOS Version
Function Keys
Award Modular BIOS v6.00PG
Copyright (C) 1984-2012, Award Software, Inc.
GA-78LMT-USB3 R2 E2
.
.
.
.
<DEL>: BIOS Setup <F12>: Boot Menu <End>: Qash
10/23/2017-RS780L-SB710-7A66IG02C-00
The Functions of the <F11> and <F12> keys (For the Main Menu Only)
` F11: Save CMOS to BIOS
This function allows you to save the current BIOS settings to a prole. You can create up to 8 proles
(Prole 1-8) and name each prole. First enter the prole name (to erase the default prole name, use the
SPACE key) and then press <Enter> to complete.
` F12: Load CMOS from BIOS
If your system becomes unstable and you have loaded the BIOS default settings, you can use this function
to load the BIOS settings from a prole created before, without the hassles of reconguring the BIOS
settings. First select the prole you wish to load and then press <Enter> to complete.
