- 22 -
2-4 Advanced BIOS Features
& IGXConguration
The settings in this submenu are synchronous to those under the same items on the MB Intelligent
Tweaker(M.I.T.) main menu.
& Load Line Control
Enables or disables Load Line control. This item allows you to adjust Vdroop at different levels. Enabling
Load-Line Calibration may keep the CPU voltage more constant under light and heavy CPU load. Auto
lets the BIOS automatically congure this setting. (Default: Auto)
& AMD C1E Support
Enables or disables the C1E CPU power-saving function in system halt state. When enabled, the power
consumption will be reduced during system halt state.
Disabled Disables this function. (Default)
Enabled If a CPU that supports hardware C1E is installed, the BIOS will automatically enable
the hardware C1E function. If not, the BIOS will enable the software C1E function.
& IDE Channel 0, 1, 2, 3 Master/Slave
IDE Channel 0, 1 Master/Slave; Extended IDE Drive
Options are:
• None If no IDE/SATA devices are used, set this item to None so the system will skip the
detection of the device during the POST for faster system startup.
• Auto Lets the BIOS automatically detect IDE/SATA devices during the POST. (Default)
• Manual Allows you to manually enter the specications of the hard drive when the hard drive
access mode is set to CHS.
Access Mode Sets the hard drive access mode. Options are: Auto (default), CHS, LBA, Large.
Capacity Approximate capacity of the currently installed hard drive.
& Halt On
Allows you to determine whether the system will stop for an error during the POST.
Options are: "All Errors," "No Errors," "All, But Keyboard". (Default)
& Memory
These elds are read-only and are determined by the BIOS POST.
CMOS Setup Utility-Copyright (C) 1984-2012 Award Software
Advanced BIOS Features
`
IGX Conguration [Press Enter]
Load Line Control [Auto]
AMD C1E Support [Disabled]
AMD C6 Support
(Note)
[Enabled]
Virtualization [Disabled]
AMD K8 Cool&Quiet control [Auto]
AMD APM Master Mode
(Note)
[Auto]
CPU core Control
(Note)
[Auto]
x One Core Per Compute Unit
(Note)
Disabled
x CPU core 1-2
(Note)
Enabled
x CPU core 3-4
(Note)
Enabled
`
Hard Disk Boot Priority [Press Enter]
EFI CD/DVD Boot Option [Auto]
First Boot Device [Hard Disk]
Second Boot Device [CDROM]
Third Boot Device [USB-HDD]
Password Check [Setup]
HDD S.M.A.R.T. Capability [Disabled]
Away Mode [Disabled]
Init Display First [PCI Slot]
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level
`
(Note) This item is present only when you install a CPU that supports this feature.
