Gigabyte GA-78LMT-USB3 R2 (rev. 1.0) [31/35] Installing the sata raid ahci driver and operating system
![Gigabyte GA-78LMT-USB3 R2 (rev. 1.0) [31/35] Installing the sata raid ahci driver and operating system](/views2/1669478/page31/bg1f.png)
- 31 -
5. Press <Ctrl>+<Y> keys to save the information. The message in Figure 1 will appear. Press <Ctrl>+<Y> to
clear the MBR or press other keys to ignore this option.
6. Then, the window below will appear. Press <Ctrl>+<Y> to set the capacity of the RAID array or press other
keys to set the array to its maximum capacity.
Figure 1
Figure 2
Fast Initialization Option has been selected
It will erase the MBR data of the disk.
<Press Ctrl-Y Key if you are sure to erase it>
<Press any other key to ignore this option>
Press Ctrl-Y to Modify Array Capacity or press any
other key to use maximum capacity...
7. After the creation is complete, the screen will return to DeneLDMenu where you will see the newly-created
array.
8. Press <Esc> to return to Main Menu and press <Esc> again if you want to exit the RAID BIOS utility.
Making a SATA RAID/AHCI Driver Diskette
Before installing Windows XP, connect a USB oppy disk drive to your computer rst because you need to install
the SATA RAID/AHCI driver from a oppy disk that contains the driver during the OS installation. To copy the
RAID/AHCI driver for Windows XP, copy all les in the \BootDrv\SBxxx\x86 folder in the motherboard driver
disk to your oppy disk. To install Windows 64-Bit, copy the les in the x64 folder.
Installing the SATA RAID/AHCI Driver and Operating System
A. Installing Windows XP
Restart your system to boot from the Windows XP setup disk and press <F6> as soon as you see the message
"Press F6 if you need to install a 3rd party SCSI or RAID driver." Insert the oppy disk containing the SATA
RAID/AHCI driver. Follow the on-screen instructions to install the driver that suits your operating system. When
completed, proceed with the Windows XP installation.
B. Installing Windows 7
Restart your system to boot from the Windows 7 setup disk and perform standard OS installation steps. Select
Load Driver. Insert the motherboard driver disk and then browse to the location of the driver. Then follow the
on-screen instructions to load the driver. The locations of the drivers for Windows 7 are as follows:
RAID driver for Windows 32-bit: \BootDrv\SBxxxW7\RAID\W7
RAID driver for Windows 64-bit: \BootDrv\SBxxxW7\RAID\W764A
AHCI driver for Windows 32-bit: \BootDrv\SBxxxW7\AHCI\Win7x86
AHCI driver for Windows 64-bit: \BootDrv\SBxxxW7\AHCI\Win7x64
After loading the driver, continue the OS installation.
