2-3 Standard CMOS Features
********
System Voltage Optimized
********
& System Voltage Control
Determines whether to manually set the system voltages. Auto lets the BIOS automatically set the system
voltages as required. Manual allows all voltage control items below to be congurable. (Default: Auto)
& NorthBridge Volt Control
Allows you to set the North Bridge voltage.
Normal Supplies the North Bridge voltage as required. (Default)
+0.1V ~ +0.3V The adjustable range is from 0.1V to 0.3V.
& DDR3 Voltage
Allows you to set memory voltage.
Normal Supplies the memory voltage as required. (Default)
1.500V ~ 1.900V The adjustable range is from 1.500V to 1.900V.
Note: Increasing memory voltage may result in damage to the memory or reduce the useful life of the
memory.
& CPU Voltage Control
Allows you to set the CPU voltage. Auto sets the CPU voltage as required. The adjustable range is
dependent on the CPU being installed. (Default: Normal)
Note: Increasing CPU voltage may result in damage to your CPU or reduce the useful life of the CPU.
& CPU NB VID Control
Allows you to set the CPU North Bridge VID voltage. Auto sets the CPU North Bridge VID voltage as
required. The adjustable range is dependent on the CPU being installed. (Default: Normal)
Note: Increasing CPU voltage may result in damage to your CPU or reduce the useful life of the CPU.
& Normal CPU Vcore
Displays the normal operating voltage of your CPU.
& Normal CPU Vcore NB
Displays the normal operating voltage of your CPU North Bridge.
& Date (mm:dd:yy)
Sets the system date.
& Time (hh:mm:ss)
Sets the system time.
CMOS Setup Utility-Copyright (C) 1984-2012 Award Software
Standard CMOS Features
Date (mm:dd:yy) Thu, Nov 2 2017
Time (hh:mm:ss) 15 : 39 : 27
`
IDE Channel 0 Master [None]
`
IDE Channel 0 Slave [None]
`
IDE Channel 1 Master [None]
`
IDE Channel 1 Slave [None]
`
IDE Channel 2 Master [None]
`
IDE Channel 2 Slave [None]
`
IDE Channel 3 Master [None]
`
IDE Channel 3 Slave [None]
Halt On [All, But Keyboard]
Base Memory 640K
Extended Memory 766M
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level
`
