• PROGRAMMING A WASH CYCLE
• DESCRIPTION OF THE CONTROL PANEL
17
EN
16
EN
4 / PROGRAMMING YOUR APPLIANCE
•Operations to perform
Display
3 / PREPARING YOUR LAUNDRY AND YOUR APPLIANCE
• LOADING YOUR LAUNDRY (continued)
• LOADING DETERGENTS
Fig. 16
cl
•Measuring the detergent
The quantity of detergent to be used depends
on the hardness of the water, the degree of
soiling of your laundry and the size of the
load.
Always refer to the quantity recommenda-
tions given on the detergent packaging.
Warning: the recommendations of detergent
manufacturers are usually for a drum filled to
the maximum. Adjust your quantity in accor-
dance with the weight of laundry in the
machine.
These recommendations will prevent exces-
sive use of detergent which causes foaming.
Over-production of foam can decrease the
performance of your machine and increase
the wash duration and water use.
•Detergents for woollens and deli-
cate fabrics
When washing these fabrics, we recommend
using a suitable detergent (avoid putting it
directly in the drum as some of these pro-
ducts are aggressive to metal).
•For dryers :
Always adhere to the manufacturer's instruc-
tions when using softening products:
1 2 3 4
To achieve the best washing performance, after sorting and unfolding, place the laundry in the
drum, not piled up but spread out evenly. Mix large and small items to achieve the best spinning,
so there is no imbalance.
Important :
When closing the drum, be careful not to trap laundry between the two doors.
Pre-washing compartment
(powder)
Washing compartment
(powder or liquid)
Bleach compartment
Fabric softener compartment
Powder detergent
Liquid detergent
4
cl
3
2
1
NB : All buttons are touch-sensitive; they do not press down. A simple touch is sufficient.
Important :
—
The "WASHING" compartment may contain powder and liquid; however, do not use liquid
detergent for programs WITH
pre-washing or WITH “delayed start” (depending on model).
—
For correct filling of detergent compartments, place the lid in its maximum opening position.
—
Do not exceed the MAX level.
(Fig. 16)
Light on: option selected
Light off: option not selected
The machine displays the most sui-
table spin speed for the program
chosen as well as the duration of
this program for a standard load.
NB : Choosing an
option changes the
cycle duration.
AA EEBB DDCC
11 22 33 44
Fig. 17
Program selector
Spin speed setting
Options and
Child Safety Selection buttons
Delayed start / Drying Time
DD
CC
BB
AA
Start/Pause
Cycle sequence indicator lights
Spin speed display
Time display
Child Safety lock indicator lights
44
33
22
11
EE
— Choose the wash cycle best suited to the type of laundry
by turning the program selector .
NB : Turning the selector to a position other than
“0”
swit-
ches the machine on.
AA
— If necessary choose options using the buttons (see
chapter “DETAILS OF OPTIONS”).
NB : You can select only the options compatible with the
program chosen.
CC
— You can change the spin speed proposed using the Spin
button
.
— Or for the end of cycle : choose drain.
The cycle will end with draining at 110 rpm without spin.
— Or : full tank stop.
Your machine will stop with a tank full of water before the
final spin.
BB
