- 11 - Hardware Installation
1-2 Product Specications
CPU Support for Intel
®
Xeon
®
E5-2600 V3/V4 series processors in the LGA2011
package
L3 cache varies with CPU
Supports Dual QuickPath Interconnect up to 9.6GT/s
Enhanced Intel SpeedStep Technology (EIST)
Support Intel Virtualization Technology (VT)
Chipset Intel
®
C612 Express (Wellsburg) Chipset
Memory 8 x DIMM slots
DDR4 memory supported only
Quad channel memory architecture
ECC RDIMM / LRDIMM modules supported
Single and dual rank RDIMM modules up to 32GB supported
3DS LRDIMM modules up to 128GB supported
1.2V modules: 1600/1866/2133/2400 MHz
LAN 4 x Intel
®
I210 supports GbE LAN ports
1 x Management LAN 10/100/1000Mpbs LAN port
Expansion Slots 1 x PCI Express x16 slot, running at x16 (Gen3/PCIE_3)
3 x PCI Express x16 slot, running at x8 (Gen3/PCIE_4/PCIE_5/PCIE_6)
2 x PCI Express x16 slot, running at x4 (Gen3/PCIE_1/PCIE_2)
1 x PCI Express mezzanine type T, running at x8 (Gen3/RAID_SLOT1&2)
Onboard
Graphics
ASPEED
®
AST2400 supports 16MB DDR3 VRAM
Storage Interface Intel
®
C612 Express controller
10 x SATA3 6Gb/s connectors (SATA0/SATA1/SATA2/SATA3/SATA4/SATA5/
SSATA0/SSATA1/SSATA2/SSATA3)
8 x SAS 6Gb/s connectors (SAS0/SAS1/SAS2/SAS3/SAS4/SAS5/SAS6/SAS7)
Activating SAS ports with Gigabyte extension card
Support for Intel RSTe SATA RAID 0/1/5/10
USB
Up to 6 USB 3.0 ports (4 on the back panel, 2 additional ports via the USB
brackets connected to the internal USB headers)
2 x USB 2.0 ports (back panel)
