Gigabyte MD50-LS0 (rev. 1.1) [41/124] Onboard lan information lan1 lan2 lan3 lan4 mac address

- 41 - BIOS Setup

Onboard LAN Information

LAN1/LAN2/LAN3/LAN4 MAC Address

Display LAN1/LAN2/LAN/LAN4 MAC address information.

System Date

Set the date following the weekday-month-day- year format.

System Time

Set the system time following the hour-minute- second format.
