Gigabyte R161-340 (rev. 100/200) [15/107] Chapter 2 system appearance

- 15 - System Appearance

1 2

Chapter 2 System Appearance

2-1 Front View

No. Description

Front Panel LEDs and buttons

2. Front USB 3.0 ports

• Refer to Chapter

2-3 Front Panel LED

and Buttons for a detailed description of the function

of the LEDs.

2-2 Rear View

No. Description

1. VGA Port

2. 1Gbe LAN Port x 2

3. USB 3.0 Port x 2

4. 10/100/1000 Server management LAN port

5. ID Button

6. PCIe Card Bay #1

7. PCIe Card Bay #2

• Refer to Chapter

2-4 Rear System LAN LEDs

for a detailed description of the function of

the LEDs.

HDD1 HDD2 HDD3 HDD4

1 2 3 4
