Hardware Installation - 11 -
1-2 Product Specications
Socket
Socket
CPU 2nd Generation Intel® Xeon® Scalable and Intel® Xeon® Scalable Processors
Intel® Xeon® Platinum Processor, Intel® Xeon® Gold Processor, Intel® Xeon®
Silver Processor and Intel® Xeon® Bronze Processor
CPU TDP up to 125W
NOTE: If only 1 CPU is installed, some PCIe or memory functions might be
unavailable
Socket
Socket
Socket 2 x LGA 3647
Socket P
Socket
Socket
Chipset
Intel® C621 Express Chipset
Socket
Socket
Memory 16 x DIMM slots
DDR4 memory supported only
6-channel memory architecture
RDIMM modules up to 64GB supported
LRDIMM modules up to 128GB supported
1.2V modules: 2933( 1DPC)/2666/2400/2133 MHz
NOTE: 2933MHz for 2nd Generation Intel® Xeon® Scalable Processors only
Socket
Socket
LAN 2 x 1Gb/s LAN ports (Intel® I210-AT)
1 x 10/100/1000 management LAN
* 2 x 10Gb/s LAN ports (Intel® X557) as an option
* 2 x 25Gb/s SFP28 ports (Mellanox® ConnectX-4 Lx) as an option
Socket
Socket
Expansion Slot Riser Card CRS1014:
- 1 x PCIe x16 slots (Gen3 x16), Full height half-length
Riser Card CRS1015:
- 1 x PCIe x16 slot (Gen3 x16), Full height half-length
2 x M.2 slots:
- M-key
- PCIe Gen3 x4
- Supports NGFF-2260/2280 cards
Socket
Socket
Video Integrated in Aspeed® AST2500
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp, DDR4 SDRAM
Socket
Socket
Storage 4 x 3.5" SATA/SAS hot-swappable HDD/SSD bays
2.5" HDD/SSD supported
SAS card is required for SAS devices support
1 x 2.5" internal xed SATA HDD/SSD bay
2 x 2.5" internal xed SATA HDD/SSD bays as an option
Socket
Socket
SATA 2 x 7-pin SATA III 6Gb/s with SATA DOM supported
By using pin_8 or external cable for power function
