- 12 - Hardware Installation
Socket
Socket
SAS Supported via add-on SAS Card
Socket
Socket
Support RAID
Function
Intel® SATA RAID 0/1/10/5
Socket
Socket
Internal
Connectors
2 x Power supply connectors
5 x SlimSAS connectors
2 x SATA 7-pin connectors
2 x CPU fan headers
1 x USB 3.0 header
1 x TPM header
1 x VROC connector
1 x Front panel header
1 x HDD back plane board header
1 x IPMB connector
1 x Clear CMOS jumper
1 x BIOS recovery jumper
Socket
Socket
Front Panel
LED/Buttons
2 x USB 3.0
1 x Power button with LED
1 x ID button with LED
1 x Reset button
1 x NMI button
1 x System status LED
1 x HDD activity LED
2 x LAN activity LEDs
Socket
Socket
Rear Panel I/O 2 x USB 3.0
1 x VGA
1 x COM (as an option)
2 x RJ45
1 x MLAN
1 x ID button with LED
Socket
Socket
Backplane I/O 4 x SATA/SAS ports
Bandwidth: SATAIII 6Gb/s or SAS 12Gb/s per port
Socket
Socket
TPM 1 x TPM header with SPI interface
Optional TPM2.0 kit: CTM010
Содержание
- R161 340 1
- Service guide 1
- Copyright 2
- Disclaimer 2
- Documentation classifications 2
- For more information 2
- Http reseller b2b gigabyte com 2
- Http www gigabyte com 2
- Conventions 3
- The following conventions are used in this user s guide 3
- Server warnings and cautions 4
- Electrostatic discharge esd 5
- Chapter 1 hardware installation 0 7
- Chapter 2 system appearance 5 7
- Chapter 3 system hardware installation 1 7
- Chapter 4 motherboard components 5 7
- Chapter 5 bios setup 9 7
- Table of contents 7
- 3 chipset setup menu 63 8
- 4 server management menu 84 8
- 5 security menu 91 8
- 6 boot menu 94 8
- 7 save exit menu 98 8
- 8 bios post codes 100 8
- 10 bios recovery instruction 107 9
- 9 bios post beep code ami standard 106 9
- 1 installation precautions 10
- Chapter 1 hardware installation 10
- 2 product specifications 11
- 14 hardware installation 14
- 3 system block diagram 14
- Aspeed ast2500 14
- Pch intel c621 lewisburg 14
- Skylake sp lga 3647 socket p0 14
- 1 front view 15
- 2 rear view 15
- Chapter 2 system appearance 15
- 3 front panel led and buttons 16
- 7 6 5 4 3 2 1 16
- No name color status description 16
- 2 1 2 2 1 17
- 4 rear system lan leds 17
- 1 depends on hba utility spec 18
- 18 system appearance 18
- 2 blink cycle depends on hdd s activity signal 18
- 3 if hdd is pulled out during rebuilding the disk status of this hdd is regarded as faulty 18
- 5 hard disk drive leds 18
- Green on off 18
- Led 2 hdd present no hdd 18
- 6 power supply unit led 19
- This page intentionally left blank 20
- Chapter 3 system hardware installation 21
- 1 removing and installing the chassis cover 22
- 2 removing and installing the fan duct 23
- 3 removing and installing the cpu and heat sink 24
- 4 1 six channel memory configuration 26
- 4 removing and installing memory 26
- Cpu0 cpu1 26
- Read the following guidelines before you begin to install the memory make sure that the motherboard supports the memory it is recommended that memory of the same capacity brand speed and chips be used always turn off the computer and unplug the power cord from the power outlet before installing the memory to prevent hardware damage memory modules have a foolproof design a memory module can be installed in only one direction if you are unable to insert the memory switch the direction 26
- System hardware installation 26 26
- This motherboard provides 16 ddr4 memory sockets and supports six channel technology after the memory is installed the bios will automatically detect the specifications and capacity of the memory 26
- 27 system hardware installation 27
- 4 2 removing and installing a memory module 27
- 4 3 dimm population table 27
- Before installing a memory module make sure to turn off the computer and unplug the power cord from the power outlet to prevent damage to the memory module be sure to install ddr4 dimms on to this motherboard 27
- Close the plastic clip at both edges of the dimm slots to lock the dimm module 27
- Follow these instructions to install a dimm module 27
- Insert the dimm memory module vertically into the dimm slot and push it down 27
- Reverse the installation steps when you want to remove the dimm module 27
- 5 removing and installing the pci expansion card 28
- 6 removing and installing the hard disk drive 29
- 7 installing and removing an m solid state drive 30
- 8 replacing the fan assembly 31
- 9 removing and installing the power supply 32
- 10 cable routing 33
- 1 motherboard components 35
- Chapter 4 motherboard components 35
- 2 jumper settings 37
- 37 motherboard components 37
- Clear cmos clr_cmos enable default 37
- Bios setup program function keys 39
- Chapter 5 bios setup 39
- Advanced 40
- Chipset 40
- Save exit 40
- Security 40
- Server management 40
- 1 the main menu 41
- 2 advanced menu 44
- 2 1 trusted computing 45
- 2 2 serial port console redirection 46
- 2 3 sio configuration 49
- 2 4 pci subsystem settings 50
- 2 5 usb configuration 52
- 2 6 post report configuration 53
- 2 7 nvme configuration 54
- 2 8 chipset configuration 55
- 2 9 network stack configuration 56
- 2 10 iscsi configuration 57
- 2 11 intel r i210 gigabit network connection 58
- 2 12 vlan configuration 60
- 2 13 driver health 62
- 3 chipset setup menu 63
- 3 1 processor configuration 64
- 3 2 common refcode configuration 67
- 3 3 upi configuration 68
- 3 4 memory configuration 69
- 3 5 iio configuration 71
- 3 6 advanced power management configuration 73
- 3 7 pch configuration 76
- 3 8 miscellaneous configuration 78
- 3 9 server me configuration 79
- 3 10 runtime error logging 80
- 3 11 power policy 82
- 4 server management menu 84
- 4 1 system event log 86
- 4 2 view fru information 87
- 4 3 bmc vlan configuration 88
- 4 4 bmc network configuration 89
- 4 5 ipv6 bmc network configuration 90
- 5 security menu 91
- 5 1 secure boot 92
- 6 boot menu 94
- 6 1 uefi network drive bbs priorities 96
- 6 2 uefi application boot priorities 97
- 7 save exit menu 98
- 8 1 ami standard pei 100
- 8 2 ami standard dxe 100
- 8 bios post codes 100
- 8 3 ami standard error 102
- 8 4 intel upi post codes 103
- 8 5 intel upi error codes 103
- 8 6 intel mrc post codes 104
- 8 7 intel mrc error codes 104
- 8 8 intel pm post codes 105
- 8 9 intel pm post codes 105
- 9 1 pei beep codes 106
- 9 2 dxe beep codes 106
- 9 bios post beep code ami standard 106
- 10 bios recovery instruction 107
