Hardware Installation - 13 -
Socket
Socket
System
Management
Aspeed® AST2500 management controller
Avocent® MergePoint IPMI 2.0 web interface:
Network settings
Network security settings
Hardware information
Users control
Services settings
IPMI settings
Sessions control
LDAP settings
Power control
Fan proles
Voltages, fans and temperatures monitoring
System event log
Events management (platform events, trap settings, email settings)
Serial Over LAN
vKVM & vMedia (HTML5)
Socket
Socket
Power Supply 1 x 550W single PSUs
80 PLUS Platinum
AC Input:
- 100-240V~/ 8-4A, 50-60Hz
DC Input:
- 240Vdc/ 2.75A
DC Output:
- 550W
+12V/ 44A
+12Vsb/ 2.1A
* Enable to upgrade to 2 x 550W redundant PSU (as an option)
Socket
Socket
Environment
Ambient
Temperature
Relative
Humidity
Operating temperature: 10°C to 35°C
Non-operating temperature: -40°C to 60°C
Operating humidity: 8-80% (non-condensing)
Non-operating humidity: 20%-95% (non-condensing)
Socket
Socket
System
Dimension
1U
438mm (W) x 43.5mm (H) x 730mm (D)
* We reserves the right to make any changes to the product specications and product-related information without
prior notice.
