English
4
- Direct Drive Technology
- PCB Isolate Shielding
- Impedance Sensing on Front Out port
-
Individual PCB Layers for R/L Audio Channel
- Gold Audio Jacks
- 15μ Gold Audio Connector
•
Supports DTS Connect
LAN
1 x 10 Gigabit LAN 100/1000/2500/5000/10000 Mb/s
(AQUANTIA® AQC107):
•
Supports Lightning/ESD Protection
•
Supports PXE
1 x Intel Gigabit LAN 10/100/1000 Mb/s (Intel® I219V):
•
Supports Wake-On-LAN
•
Supports Lightning/ESD Protection
•
Supports Energy Ecient Ethernet 802.3az
•
Supports PXE
Wireless
LAN
•
Intel® 802.11ax WiFi Module
•
Supports IEEE 802.11a/b/g/n/ax
•
Supports Dual-Band (2.4/5 GHz)
•
Supports high speed wireless connections up to 2.4Gbps
•
2 antennas to support 2 (Transmit) x 2 (Receive) diversity
technology
•
Supports Bluetooth 5.0 + High speed class II
•
Supports MU-MIMO
Rear Panel
I/O
•
2 x Antenna Ports
•
1 x Optical SPDIF Out Port
•
2 x USB 2.0 Ports (Supports ESD Protection)
•
2 x USB 3.2 Gen2 underbolt
TM
3 Type-C Ports (40Gb/s for
underbolt protocol; 10 Gb/s for USB3.2 protocol) (Supports
ESD Protection)*
* Supports USB-PD 3.0 9V/3A(27W) and 5V/3A(15W)
•
2 x Mini DisplayPort Input Ports**
** Please choose regular mini DisplayPort to DisplayPort
adapter cables instead of right angled ones if you use two mini
DisplayPort input ports simultaneously.
•
4 x USB 3.2 Gen1 Ports (Supports ESD Protection)***
