English
16
Step 3
Follow step 2 to connect the other Mini DisplayPort Input Port to the graphics card.
Step 4
Connect the underbolt
TM
cable(s) from your underbolt-enabled device(s) to the
USB 3.2 Gen2 underbolt
TM
3 Type-C Port(s) on ASRock underbolt
TM
3 Module
on I/O panel.
1. Make sure to connect both Mini DisplayPort Input Ports if you install the under-
bolt
TM
output display device.
2. Please choose regular Mini DisplayPort to DisplayPort Adapter Cables instead of
right angled ones if you use two Mini DisplayPort Input Ports simultaneously.
