ASRock X299 Creator [32/122] English
![ASRock X299 Creator [32/122] English](/views2/1686108/page32/bg20.png)
English
25
X299 Creator
PCIE1 PCIE2 PCIE3 PCIE4 PCIE5
Single Graphics Card x16 N/A N/A N/A N/A
Two Graphics Cards in
CrossFireX
TM
or SLI
TM
Mode
x16 N/A x16 N/A N/A
ree Graphics Cards in
3-Way CrossFireX
TM
Mode
or 3-Way SLI
TM
Mode
x16 N/A x16 N/A x8
If a M.2 PCI Express module is installed on M2_1 or M2_2, PCIE2 will downgrade to x4 mode.
If M.2 PCI Express modules are installed on M2_1 and M2_2, PCIE2 will be disabled.
PCIe Slot Congurations (For CPU with 44 PCIe lanes)
PCIe Slot Congurations (For CPU with 28 PCIe lanes)
PCIE1 PCIE2 PCIE3 PCIE4 PCIE5
Single Graphics Card x16 N/A N/A N/A N/A
Two Graphics Cards in
CrossFireX
TM
or SLI
TM
Mode
x16 N/A x8 N/A N/A
If a M.2 PCI Express module is installed on M2_1, PCIE2 will be disabled.
* If you install CPU with 44 or 28 lanes and encounter CrossFire issues, please
do the followings.
1. Enter UEFI by pressing <F2> or <Del> during system startup.
2. Select “Boot > CSM” from the menu.
3. Set "Launch Storage OpROM policy" to "UEFI only".
4. Press F10 to Save and Exit.
For a better thermal environment, please connect a chassis fan to the motherboard’s
chassis fan connector (CHA_FAN1/WP, CHA_FAN2/WP, CHA_FAN3/WP, CHA_
FAN4/WP or CHA_FAN5/WP) when using multiple graphics cards.
PCIE1 PCIE2 PCIE3 PCIE4 PCIE5
Single Graphics Card x16 N/A N/A N/A N/A
Two Graphics Cards in
CrossFireX
TM
or SLI
TM
Mode
x16 N/A x16 N/A N/A
ree Graphics Cards in
3-Way CrossFireX
TM
Mode
or 3-Way SLI
TM
Mode
x16 N/A x16 N/A x8
If a M.2 PCI Express module is installed on M2_1, PCIE2 will be disabled.
