2.7 Smart Switches
e motherboard has three smart switches: Power Button, Reset Button and Clear
CMOS Button, allowing users to quickly turn on/o the system, reset the system or
clear the CMOS values.
Power Button
(PWRBTN)
(see p.8, No. 23)
Power Button allows users
to quickly turn on/o the
system.
Reset Button
(RSTBTN)
(see p.8, No. 24)
Reset Button allows
users to quickly reset the
system.
Clear CMOS Button
(CLRCBTN1)
(see p.10, No. 15)
Clear CMOS Button
allows users to quickly
clear the CMOS values.
Power
is function is workable only when you power o your computer and unplug the
power supply.
