2.5 Installation of Memor2.5 Installation of Memor

2.5 Installation of Memor

y Modules (DIMM)y Modules (DIMM)

y Modules (DIMM)

This motherboard provides two 240-pin DDR2 (Double Data Rate 2) DIMM slots and

four 240-pin DDR3 (Double Data Rate 3) DIMM slots, and supports Dual Channel

Memory Technology. For dual channel configuration, you always need to install

identical (the same brand, speed, size and chip-type) DDR2/DDR3 DIMM pair in

the slots of the same color. In other words, you have to install identical DDR2

DIMM pair in Dual Channel A (DDRII_1 and DDRII_2; Yellow slots; see p.11 No.7),

identical DDR3 DIMM pair in Dual Channel B (DDR3_A1 and DDR3_B1; Green

slots; see p.11 No.8), or identical DDR3 DIMM pair in Dual Channel C (DDR3_A2

and DDR3_B2; Pink slots; see p.11 No.9), so that Dual Channel Memory Technol-

ogy can be activated. This motherboard also allows you to install four DDR3 DIMMs

for dual channel configuration, and please install identical DDR3 DIMMs in all four

slots. You may refer to the Dual Channel Memory Configuration Table below.

DDR3_A1 DDR3_A2 DDR3_B1 DDR3_B2

(Green Slot) (Pink Slot) (Green Slot) (Pink Slot)

2 memory modules SS X SS X

2 memory modules DS X DS X

2 memory modules X SS X SS

2 memory modules X DS X DS

4 memory modules SS SS SS SS

4 memory modules DS DS DS DS

Dual Channel DDR3 Memory Configurations

(DS: Double Side, SS: Single Side)

DDRII_1 DDRII_2

(Yellow Slot) (Yellow Slot)

2 memory modules SS SS

2 memory modules DS DS

Dual Channel DDR2 Memory Configurations

(DS: Double Side, SS: Single Side)
