BIOS SETUP UTILITY
Main
Advanced H/W Monitor Boot Security Exit
System Overview
System Time
System Date
[ :00:09]
[Wed 04/23/2008]
Use [Enter], [TAB]
or [SHIFT-TAB] to
select a field.
Use [+] or [-] to
configure system Time.
Select Screen
Select Item
+- Change Field
Tab Select Field
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
BIOS Version
Processor Type
Processor Speed
Microcode Update
Total Memory
Cache Size
DDRII1
DDRII2
DDR3_1
DDR3_2
DDR3_3
DDR3_4
: X48TurboTwins-WiFi P1.00
: Intel (R) Core(TM)2 Duo CPU
E8200 @ 2.66GHz (64bit)
: 2666MHz
: 6144KB
: 10676/60B
: 1024MB
: 1024MB/333MHz (DDR2 667)
: None
: None
: None
: None
: None
v02.54 (C) Copyright 1985-2005, American Megatrends, Inc.
14
3.1.23.1.2
3.1.23.1.2
3.1.2
Navigation KeysNavigation Keys
Navigation KeysNavigation Keys
Navigation Keys
Please check the following table for the function description of each navigation key.
Navigation Key(s) Function Description
/ Moves cursor left or right to select Screens
/ Moves cursor up or down to select items
+ / - To change option for the selected items
<Enter> To bring up the selected screen
<F1> To display the General Help Screen
<F9> To load optimal default values for all the settings
<F10> To save changes and exit the BIOS SETUP UTILITY
<ESC> To jump to the Exit Screen or exit the current screen
3.23.2
3.23.2
3.2
Main ScreenMain Screen
Main ScreenMain Screen
Main Screen
When you enter the BIOS SETUP UTILITY, the Main screen will appear and display the
system overview.
X48TurboTwins-WiFi
System Time [Hour:Minute:Second]
Use this item to specify the system time.
System Date [Day Month/Date/Year]
Use this item to specify the system date.
