ASRock X48TurboTwins-WiFi [37/71] 3 7 3 7 3 7 3 7

3737

Comparison between eSATAII and other devices

IEEE 1394 400Mb/s

USB 2.0 480Mb/s

SATA 1.5Gb/s (1500Mb/s)

eSATAII/SATAII 3.0Gb/s (3000Mb/s)

Connect one end of the eSATAII

device cable to eSATAII device

Connect the other end of the eSATAII

device cable to eSATAII port of the I/O

shield

3. Use the eSATAII device cable to connect eSATAII device and the eSATAII port of

the I/O shield.
