AB350M-HDV R3.0 / A320M-HDV R3.0 / A320M-DVS R3.0
5
English
Storage
•
4 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0,
RAID 1 and RAID 10), NCQ, AHCI and Hot Plug
•
1 x Ultra M.2 Socket, supports M Key type 2242/2260/2280
M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up
to Gen3 x4 (32 Gb/s) (with Summit Ridge, Raven Ridge and
Pinnacle Ridge) or Gen3 x2 (16 Gb/s) (with A-Series APU)*
(for AB350M-HDV R3.0 / A320M-HDV R3.0 only)
* Supports NVMe SSD as boot disks
* Supports ASRock U.2 Kit
Connector
•
1 x COM Port Header
•
1 x TPM Header
•
1 x Chassis Intrusion and Speaker Header
•
1 x CPU Fan Connector (4-pin)
•
2 x Chassis Fan Connectors (1 x 4-pin, 1 x 3-pin)
* e CPU Fan Connector supports the CPU fan of maximum
1A (12W) fan power.
•
1 x 24 pin ATX Power Connector
•
1 x 4 pin 12V Power Connector
•
1 x Front Panel Audio Connector
•
2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD
Protection)
•
1 x USB 3.1 Gen1 Header (Supports 2 USB 3.1 Gen1 ports)
(Supports ESD Protection)
BIOS
Feature
•
AMI UEFI Legal BIOS with GUI support
•
Supports “Plug and Play”
•
ACPI 5.1 compliance wake up events
•
Supports jumperfree
•
SMBIOS 2.3 support
•
DRAM Voltage multi-adjustment
Hardware
Monitor
•
CPU/Chassis temperature sensing
•
CPU/Chassis Fan Tachometer
•
CPU/Chassis Quiet Fan
•
CPU/Chassis Fan multi-speed control
•
CASE OPEN detection
•
Voltage monitoring: +12V, +5V, +3.3V, Vcore
Содержание
- California usa only 2
- Copyright notice 2
- Disclaimer 2
- Australia only 3
- Chapter 1 introduction 1 4
- Chapter 2 installation 13 4
- Chapter 3 software and utilities operation 37 4
- Contents 4
- Chapter 4 uefi setup utility 47 5
- Ab350m hdv r3 a320m hdv r3 a320m dvs r3 6
- Chapter 1 introduction 6
- English 6
- Package contents 6
- Chipset 7
- English 7
- Memory 7
- Platform 7
- Specifications 7
- Ab350m hdv r3 a320m hdv r3 a320m dvs r3 8
- English 8
- Expansion slot 8
- Graphics 8
- English 9
- Rear panel i o 9
- Ab350m hdv r3 a320m hdv r3 a320m dvs r3 10
- Bios feature 10
- Connector 10
- English 10
- Hardware monitor 10
- Storage 10
- Certifica tions 11
- English 11
- Erp eup ready erp eup ready power supply is required 11
- Fcc ce 11
- Microsoft windows 10 64 bit 11
- Ab350m hdv r3 a320m hdv r3 12
- Ab350m hdv r3 a320m hdv r3 a320m dvs r3 12
- Atxpwr1 12
- English 12
- Motherboard layout 12
- A320m dvs r3 13
- Atxpwr1 13
- English 13
- Ab350m hdv r3 a320m hdv r3 a320m dvs r3 14
- English 14
- Ab350m hdv r3 a320m hdv r3 15
- English 15
- I o panel 15
- A320m dvs r3 16
- Ab350m hdv r3 a320m hdv r3 a320m dvs r3 16
- English 16
- English 17
- Ab350m hdv r3 a320m hdv r3 a320m dvs r3 18
- Chapter 2 installation 18
- English 18
- Pre installation precautions 18
- English 19
- Installing the cpu 19
- English 21
- Installing the cpu box cooler sr1 21
- Installing the cpu fan and heatsink 21
- Ab350m hdv r3 a320m hdv r3 a320m dvs r3 22
- English 22
- English 23
- Installing the am4 box cooler sr2 23
- English 25
- Installing the am4 box cooler sr3 26
- English 27
- Ab350m hdv r3 a320m hdv r3 a320m dvs r3 28
- English 28
- A series apus 29
- Ddr4 udimm maximum frequency support 29
- English 29
- Installing memory modules dimm 29
- Ryzen series cpus pinnacle ridge 29
- Ab350m hdv r3 a320m hdv r3 a320m dvs r3 30
- English 30
- Ryzen series cpus raven ridge 30
- Ryzen series cpus summit ridge 30
- English 31
- Ab350m hdv r3 a320m hdv r3 a320m dvs r3 32
- English 32
- Expansion slots pci express slots 32
- Pcie slot configurations 32
- English 33
- Jumpers setup 33
- Ab350m hdv r3 a320m hdv r3 a320m dvs r3 34
- Connect the power button reset button and system status indicator on the chassis to this header according to the pin assignments below note the positive and negative pins before connecting the cables 34
- English 34
- Onboard headers and connectors 34
- System panel header 9 pin panel1 see p 8 no 12 34
- English 35
- Ab350m hdv r3 a320m hdv r3 a320m dvs r3 36
- English 36
- English 37
- Ab350m hdv r3 a320m hdv r3 a320m dvs r3 38
- English 38
- Installing the m _ssd ngff module 38
- M _ssd ngff module installation guide for ab350m hdv r3 a320m hdv r3 only 38
- English 39
- Ab350m hdv r3 a320m hdv r3 a320m dvs r3 40
- English 40
- English 41
- M _ssd ngff module support list 41
- Ab350m hdv r3 a320m hdv r3 a320m dvs r3 42
- Chapter 3 software and utilities operation 42
- Drivers menu 42
- English 42
- Installing drivers 42
- Running the support cd 42
- Utilities menu 42
- A tuning 43
- English 43
- Installing a tuning 43
- Operation mode 43
- Using a tuning 43
- English 45
- Fan tastic tuning 45
- Settings 45
- Ab350m hdv r3 a320m hdv r3 a320m dvs r3 46
- Asrock live update app shop 46
- English 46
- Ui overview 46
- English 47
- Installing an app 47
- Ab350m hdv r3 a320m hdv r3 a320m dvs r3 48
- English 48
- English 49
- Upgrading an app 49
- Ab350m hdv r3 a320m hdv r3 a320m dvs r3 50
- Bios drivers 50
- English 50
- Installing bios or drivers 50
- English 51
- Setting 51
- Ab350m hdv r3 a320m hdv r3 a320m dvs r3 52
- Chapter 4 uefi setup utility 52
- English 52
- Introduction 52
- Uefi menu bar 52
- English 53
- Navigation keys 53
- Main screen 54
- Cpu configuration 55
- Cpu frequency and voltage change 55
- English 55
- Oc mode change switch 55
- Oc tweaker screen 55
- Smt mode 55
- Ab350m hdv r3 a320m hdv r3 a320m dvs r3 56
- Cas latency tcl 56
- Dram frequency 56
- Dram information 56
- Dram timing configuration 56
- English 56
- Fail count 56
- Primary timing 56
- Ras active time tras 56
- Ras to cas delay to read trcdrd 56
- Ras to cas delay to write trcdwr 56
- Row precharge time trp 56
- Secondary timing 56
- English 57
- Four activate window tfaw 57
- Ras to ras delay trrd_l 57
- Ras to ras delay trrd_s 57
- Refresh cycle time 57
- Trcpage tmaw mac 57
- Trdrdscl 57
- Twrwrscl 57
- Write recovery time twr 57
- Write to read delay twtr_l 57
- Write to read delay twtr_s 57
- Ab350m hdv r3 a320m hdv r3 a320m dvs r3 58
- Cas write latency tcwl 58
- English 58
- Read to precharge trtp 58
- Refresh cycle time trfc 58
- Refresh cycle time trfc2 58
- Refresh cycle time trfc4 58
- Twrwrsc 58
- Twrwrsd 58
- Cad bus configuration 59
- Command rate cr 59
- Data bus configuration 59
- English 59
- Gear down mode 59
- Power down enable 59
- Procodt 59
- Trdrddd 59
- Trdrdsc 59
- Trdrdsd 59
- Twrwrdd 59
- Active page on entry 61
- Advanced screen 61
- English 61
- Full hd uefi 61
- Uefi configuration 61
- Ab350m hdv r3 a320m hdv r3 a320m dvs r3 62
- Amd ftpm switch 62
- Cool n quiet 62
- Cpu configuration 62
- English 62
- Svm mode 62
- North bridge configuration 63
- Ab350m hdv r3 a320m hdv r3 a320m dvs r3 64
- Deep sleep 64
- English 64
- Front panel 64
- Onboard hd audio 64
- Restore on ac power loss 64
- South bridge configuration 64
- English 65
- Sata controller s 65
- Sata hot plug 65
- Sata mode 65
- Storage configuration 65
- Super io configuration 66
- Acpi configuration 67
- Acpi hpet table 67
- English 67
- Pcie devices power on 67
- Ps 2 keyboard power on 67
- Rtc alarm power on 67
- Suspend to ram 67
- Trusted computing 68
- Amd cbs 69
- Core performance boost 69
- Enable ibs 69
- English 69
- Global c state control 69
- L2 tlb associativity 69
- Platform first error handling 69
- Redirectforreturndis 69
- Zen common options 69
- Ab350m hdv r3 a320m hdv r3 a320m dvs r3 70
- Core thread enablement 70
- Df common options 70
- Disable df sync flood propagation 70
- Downcore control 70
- Dram scrub time 70
- English 70
- Freeze df module queues on error 70
- Oc mode 70
- Opcache control 70
- Redirect scrubber control 70
- Sev es asid space limit 70
- Streaming stores control 70
- Cc6 memory region encryption 71
- Channel interleaving hash 71
- Control gmi link encryption 71
- Control xgmi link encryption 71
- English 71
- Gmi encryption control 71
- Location of private memory regions 71
- Memory clear 71
- Memory interleaving 71
- Memory interleaving size 71
- System probe filter 71
- Ab350m hdv r3 a320m hdv r3 a320m dvs r3 74
- Acs enable 74
- Cldo_vddp control 74
- Ctdp control 74
- Determinism slider 74
- Enables alternative routing id interpretation 74
- English 74
- Fan control 74
- Fch common options 74
- Hd audio enable 74
- Pcie ari support 74
- Sata configuration options 74
- Amd pbs 77
- Ab350m hdv r3 a320m hdv r3 a320m dvs r3 78
- Easy raid installer 78
- English 78
- Instant flash 78
- Internet flash dhcp auto ip auto 78
- Ab350m hdv r3 a320m hdv r3 a320m dvs r3 80
- Case open feature 80
- Chassis fan 1 setting 80
- Chassis fan 1 temp source 80
- Cpu fan 1 setting 80
- English 80
- Hardware health event monitoring screen 80
- Over temperature protection 80
- English 81
- Secure boot 81
- Security screen 81
- Supervisor password 81
- User password 81
- Ab350m hdv r3 a320m hdv r3 a320m dvs r3 82
- Boot beep 82
- Boot from onboard lan 82
- Boot screen 82
- Bootup num lock 82
- English 82
- Fast boot 82
- Full screen logo 82
- Setup prompt timeout 82
- Above 4g decoding 83
- Addon rom display 83
- Csm compatibility support module 83
- English 83
- Launch pxe oprom policy 83
- Launch storage oprom policy 83
- Ab350m hdv r3 a320m hdv r3 a320m dvs r3 84
- Discard changes 84
- Discard changes and exit 84
- English 84
- Exit screen 84
- Launch efi shell from filesystem device 84
- Load uefi defaults 84
- Save changes and exit 84
- Asrock america inc 85
- Asrock europe b v 85
- Asrock incorporation 85
- Contact information 85
- Ab350m hdv r3 a320m hdv r3 a320m dvs r3 86
- Declaration of conformity 86
- Directive 2014 30 eu from april 20th 2016 87
- Eu declaration of conformity 87
- Lvd directive 2014 35 eu from april 20th 2016 87
