ASRock AB350M-HDV R3.0 [9/87] English
![ASRock AB350M-HDV R3.0 [9/87] English](/views2/1691293/page9/bg9.png)
English
4
•
Supports DVI-D with max. resolution up to 1920x1200 @
60Hz
•
Supports D-Sub with max. resolution up to 2048x1536 @
60Hz
•
Supports HDCP with DVI-D Port
•
Supports Full HD 1080p Blu-ray (BD) playback with DVI-D
Port
Audio
•
7.1 CH HD Audio (Realtek ALC887 Audio Codec)
* To congure 7.1 CH HD Audio, it is required to use an HD
front panel audio module and enable the multi-channel audio
feature through the audio driver.
•
Supports Surge Protection
•
ELNA Audio Caps
LAN
•
PCIE x1 Gigabit LAN 10/100/1000 Mb/s
•
Realtek RTL8111GR
•
Supports Wake-On-LAN
•
Supports Lightning/ESD Protection
•
Supports Energy Ecient Ethernet 802.3az
•
Supports PXE
Rear Panel
I/O
•
1 x PS/2 Mouse/Keyboard Port
•
2 x USB 2.0 Ports (Supports ESD Protection)
•
4 x USB 3.1 Gen1 Ports (Supports ESD Protection)
•
1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED
LED)
•
HD Audio Jacks: Line in / Front Speaker / Microphone
AB350M-HDV R3.0 / A320M-HDV R3.0:
•
1 x D-Sub Port
•
1 x DVI-D Port
•
1 x HDMI Port
A320M-DVS R3.0:
•
1 x D-Sub Port
•
1 x DVI-D Port
