7
Rear I/O
VGA 0
HDMI 2
DVI-I/D 0
DisplayPort 1
Ethernet 1
USB
4 (3 x USB 3.0 compliant, 1 x USB 3.1 Type
C)
Audio 1 (Mic-in, Line-out)
Serial 0
e-SATA 0
PS/2 0
Internal
Connector
USB 0
LVDS/
inverter
0
VGA 0
Serial 0
SATA 1 x SATA3 ( 6.0Gb/s)
M.2 for Wi-
Fi
1 (TYPE 2230)
M.2 for SSD 1 (TYPE 2260/2280)
Parallel 0
IrDA 1
GPIO 0
SATA PWR
Output Con
1
Speaker
Header
0
Watchdog
Timer
Output 0
Interval 0
Power
Requirements
Input PWR 19V / 65W DC-In (DC Jack)
Power On
ATX Supported
ATX: Press Button to PWR on after Power
input ready
Environment Temperature 0ºC – 60ºC
