6
1.2 Specications
Form
Factor
Dimensions 4.09" x 4.02" (104 x 102mm)
Processor
System
CPU
Intel
®
6
th
Gen Core U Processor (Core i3-6100U)
Intel
®
6
th
Gen Core U Processor (Core i5-6300U)
Core
Number
2
Max Speed (By CPU)
L2 Cache 3MB
Chipset (By CPU)
BIOS UEFI
Expansion
Slot
M.2 for Wi-
Fi
1 (TYPE 2230)
M.2 for SSD
1 x M.2 (Key M, 2260/2280) with PCIEx4 and
SATA3
Memory
Technology Dual Channel DDR4 2133 MHz
Max. 32GB
Socket 2 x SO-DIMM
Graphics
Controller Intel
®
HD Graphics 520
VRAM Shared Memory
VGA N/A
LVDS N/A
HDMI
HDMI 1: Supports max resolution up to
4Kx2K@60Hz
HDMI 2 : Supports max resolution up to
4Kx2K@30Hz
DVI N/A
DisplayPort
Supports max resolution up to
4096x2160@60Hz
Multi Display
Dual Display, supports HDMI 2 + DP or HDMI 1
+ HDMI 2
Ethernet
Ethernet 10/100/1000 Mbps
Controller
1 x Intel i219V (non vPro) (Core i3-6100U)
1 x Intel i219LM (vPro, TPM) (Core i5-6300U)
Connector 1 x RJ-45
SATA
Max Data
Transfer
Rate
SATA3 (6.0Gb/S)
Содержание
- Nuc 6100u 6300u 1
- User manual 1
- California usa only 2
- Copyright notice 2
- Disclaimer 2
- Caution 3
- Contents 4
- Installation 10 4
- Introduction 5 4
- Software support 31 4
- Uefi setup utility 14 4
- Chapter 1 introduction 5
- Package contents 5
- Specifications 6
- Ddr4_a1 support ddr4l only 8
- Ddr4_b1 support ddr4l only 8
- Motherboard layout 8
- Activity link led speed led 9
- I o panel 9
- Lan port led indications 9
- Off no link off 10mbps connection blinking data activity off 100mbps connection on link green 1gbps connection 9
- Status description status description 9
- There are two led next to the lan port please refer to the table below for the lan port led indications 9
- Chapter 2 installation 10
- Pre installation precautions 10
- Screw holes 10
- Ends fully snap back in place and the so dimm is properly seated ends fully snap back in place and the so dimm is properly seated 11
- Installation of memory modules so dimm 11
- Matches the break on the slot matches the break on the slot 11
- Nuc 6100u 6300u provides two 204 pin ddr4 double data rate 4 so dimm slots 11
- Step 1 align a so dimm on the slot such that the notch on the so dimm 11
- Step 2 firmly insert the so dimm into the slot until the retaining clips at both 11
- Expansion slots m slots 12
- Installing an expansion card 12
- Onboard headers and connectors 13
- Chapter 3 uefi setup utility 14
- Introduction 14
- Uefi menu bar 14
- Main screen 15
- Navigation keys 15
- Advanced screen 16
- Cpu configuration 17
- Chipset configuration 19
- Storage configuration 21
- Super io configuration 22
- Acpi configuration 23
- Usb configuration 24
- Trusted computing 25
- Hardware health event monitoring screen 26
- Security screen 27
- Boot screen 28
- Exit screen 30
- Chapter 4 software support 31
