![ASRock 2U4FH-12L [12/40] English](/views2/1694128/page12/bgc.png)
6 7
English
No. Item
1 Server Board (SB)
2 Riser Card Assembly
3
Add-in Card Slots: 2 x PCIE Add-in Cards (on the riser card assembly)*
Mezzanine Slot: 1 x Storage Mezzanine Card (on the server board)**
4
Add-in Card Slots: 2 x PCIE Add-in Cards (on the riser card assembly)*
Mezzanine Slot: 1 x LAN Mezzanine Card (on the server board)**
5 Power Supply Unit (PSU2)
6 Power Supply Unit (PSU1)
7 4 x Power Distribution Boards (PDB)
8 System Fan (FAN1)
9 System Fan (FAN2)
10 System Fan (FAN3)
11 System Fan (FAN4)
12 HDD Backplane Board (BPB)
13 Front Panel Board (FPB)
14 VGA Port
15 12 x 3.5'' Hot-Swap HDD Trays (HDD0~HDD11)
*Supports Low prole and FHHL (Full High Half Length) PCIe cards
**Supports 1GbE x 2, 10GbE x2 or SFP+ (Fiber) mezzaine cards (M350R/M540R/M599R/M599RS)
