Chapter 1 Introduction
ank you for purchasing 2U4FH-12L, a reliable barebone system produced
under ASRockRack’s consistently stringent quality control. It delivers excellent
performance with robust design conforming to ASRockRack’s commitment to
quality and endurance.
1. Because the hardware specications might be updated, the content of this documentation
will be subject to change without notice. In case any modications of this documentation
occur, the updated version will be available on ASRockRack’s website without further
notice. If you require technical support related to this product, please visit our website for
specic information about the model you are using.
ASRockRack’s Website: www.ASRockRack.com
2. e illustrations shown in this manual are examples only, the actual system may dier
slightly .
